The LT1763CS8#TR is a high-performance low dropout voltage regulator (LDO) from Linear Technology, renowned for its exceptional noise and dropout characteristics. This regulator is designed for applications that require a clean and stable power supply, making it a perfect choice for sensitive analog circuits, high-end audio equipment, and precision instruments.

Key Features

• Low Noise Output: With an ultra-low noise output of just 20μV RMS, the LT1763CS8#TR ensures that power supply noise does not compromise the performance of the connected load.
• Low Dropout Voltage: The device offers an impressive low dropout voltage, typically 300mV at full load, which allows for efficient operation even when the input-to-output voltage differential is small.
• Adjustable and Fixed Output Voltages: The LT1763CS8#TR comes in both adjustable versions, with an output voltage range from 1.22V to 20V, and fixed versions at 1.8V, 2.5V, 3.3V, and 5V, catering to a wide array of power requirements.
• High Output Current: This regulator can deliver up to 500mA of continuous output current, suitable for a variety of applications.
• Stable with Low ESR Output Capacitors: The LT1763CS8#TR remains stable with ceramic, tantalum, and aluminum electrolytic capacitors, providing flexibility in design.
• Overcurrent and Overtemperature Protection: Built-in protection mechanisms ensure that the device and the system are safeguarded against adverse conditions.

Applications

The LT1763CS8#TR's exceptional performance characteristics make it ideal for use in:

• High-end audio equipment
• Precision data acquisition systems
• Battery-powered devices
• Portable communications equipment
• Medical devices
• Linear power supplies

Package and Availability

The LT1763CS8#TR is available in an 8-lead SOIC package, which is suitable for surface-mount technology (SMT) and is compatible with automated assembly processes. The "#TR" designation indicates that the product is provided in tape and reel packaging, facilitating efficient handling and manufacturing.

With its robust feature set and versatile applications, the LT1763CS8#TR from Linear Technology stands out as a reliable choice for designers looking to enhance the performance and stability of their power supply solutions.
