LT3014EDD Low Dropout Voltage Linear Regulator by Linear Technology

The LT3014EDD is a high-performance, low dropout voltage (LDO) linear regulator designed by Linear Technology, a leader in the field of analog integrated circuits. This compact and efficient regulator is housed in a DFN-8 package, making it an excellent choice for space-constrained applications.

Key Features:

• Wide Input Voltage Range: The LT3014EDD operates with an input voltage range from 4V to 80V, providing versatile power supply options for various electronic devices and systems.
• Low Dropout Voltage: It has a low dropout voltage of only 350mV at full load, ensuring efficient operation even when the input voltage is close to the output voltage.
• Adjustable Output: The output voltage can be set from 1.22V to 60V with a single external resistor, offering flexibility to match specific requirements of the load.
• Low Quiescent Current: With a quiescent current of only 30µA (operating) and 1µA in shutdown, the LT3014EDD is ideal for battery-powered and energy-sensitive applications.
• Thermal Protection: It includes internal thermal shutdown protection that safeguards the device against excessive temperature and potential thermal damage.
• Current Limit Protection: The built-in current limit protection ensures that the device remains within safe operating limits, preventing damage from overcurrent conditions.

Applications:

The LT3014EDD is suitable for a wide range of applications, including but not limited to:

• Automotive and Industrial Systems
• Telecommunications Infrastructure
• Portable and Battery-Powered Equipment
• Power Supply for Sensors and Control Systems
• Avionics and Military Hardware

Product Summary:

The LT3014EDD from Linear Technology stands out with its high input voltage capabilities, low dropout performance, and adjustable output voltage, making it an extremely versatile choice for designers looking to optimize power management in their systems. Its low quiescent current and robust protection features further enhance its suitability for a broad range of applications where efficiency and reliability are paramount.
