Linear Technology LT3045EDD#PBF

The LT3045EDD#PBF is a high-performance, low dropout linear regulator (LDO) from Linear Technology, designed to deliver a continuous output current of up to 500mA with outstanding power supply rejection ratio (PSRR) and low noise characteristics. This precision LDO is an ideal choice for sensitive analog circuits, such as precision instrumentation, audio amplifiers, and reference circuits, where a stable and clean power supply is paramount.

Key Features:

• High Current Output: Capable of delivering up to 500mA of continuous output current.
• Ultra-Low Noise: Offers an ultra-low output noise of only 2µVRMS (10Hz to 100kHz), making it perfect for noise-sensitive applications.
• Exceptional PSRR: Features high PSRR of >76dB at 1MHz, ensuring excellent power supply ripple rejection.
• Wide Input Voltage Range: Operates with an input voltage range from 1.8V to 20V, providing flexibility in various power supply designs.
• Adjustable Output Voltage: The output voltage is adjustable from 0V to 15V, allowing for a wide range of applications.
• Stable with Low ESR Ceramic Capacitors: Stable operation with ceramic output capacitors as low as 10µF, reducing required board space and component cost.
• Fast Transient Response: Exhibits a fast transient response, critical for maintaining output voltage stability during sudden load changes.
• Overcurrent and Overtemperature Protection: Built-in protection mechanisms safeguard the device against adverse conditions.
• Thermal Performance: The DFN package provides excellent thermal performance in a compact footprint.

Applications:

• High-precision analog circuits
• High-end audio equipment
• Medical equipment
• Power supplies for RF and mixed-signal ASICs
• Test and measurement systems

The LT3045EDD#PBF is available in a 12-lead (3mm × 3mm) DFN package, which is RoHS compliant and has a thermal pad for enhanced thermal dissipation. With its combination of features, this LDO is an excellent choice for designers looking to maximize performance in applications requiring the cleanest and most stable power supply.
