Products specifications

Categories Integrated Circuits (ICs)
Manufacturer Linear Technology
Packaging Reel package
Function Step-Up, Step-Up/Step-Down
Output Configuration Positive or Negative
Topology Boost, Cuk, SEPIC
Output Type Adjustable
Number of Outputs 1
Input Voltage MIN 2.5V
Voltage Input MAX 32V
Output Voltage 5V
Output Voltage MAX 42V (Switch)
Output Current 2A (Switch)
Frequency - Switching 200kHz ~ 2MHz
Synchronous Rectifier No
Operating Temperature Range -40°C ~ 125°C (TJ)
Mounting SMD
Package 8-WFDFN Exposed Pad
Manufacturer Package 8-DFN (3x3)
Win Source Part Number 781138-LT3580IDD#TRPBF
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian LT3580IDD#TRPBF CAD Model

Description

Linear Technology's LT3580IDD#TRPBF Boost/Inverting DC/DC Converter

The LT3580IDD#TRPBF is a versatile and compact DC/DC converter produced by Linear Technology, a brand of Analog Devices. This component is designed to cater to a wide range of applications, including those requiring a boost, flyback, SEPIC or inverting power supply configurations. The LT3580 is a highly integrated solution that simplifies the design process for engineers, offering flexibility and reliability in various electronic products.

Key Features:

  • Wide Input Voltage Range: The device operates from a 2.5V to 32V input voltage range, making it suitable for applications with varying power sources, from single-cell Li-Ion batteries to fixed 12V or 24V rails.
  • Adjustable Switching Frequency: With a switching frequency that can be set from 200kHz to 2.5MHz via a single resistor, designers can optimize the converter for efficiency or component size.
  • High Efficiency: The LT3580IDD#TRPBF can deliver efficiencies up to 85%, ensuring minimal power loss and heat generation within the system.
  • Integrated 2A, 42V Switch: The inclusion of a high voltage 2A internal switch allows for a wide range of output voltages and reduces the need for external components.
  • Robust Protection Features: The device includes a soft-start function to prevent inrush current at startup, thermal protection, and a robust short-circuit protection mechanism.

Applications:

The LT3580IDD#TRPBF is ideal for a variety of applications where a compact and efficient power conversion is required. These applications include but are not limited to:

  • Portable Battery-Powered Devices
  • Industrial Power Supplies
  • Automotive and Avionics Power Systems
  • Medical Devices
  • Telecommunications Equipment

With a small footprint in a low-profile (0.75mm) 8-lead DFN package, the LT3580IDD#TRPBF is designed to fit into space-constrained applications while providing a powerful and flexible power management solution. Its ability to create a negative voltage from a positive input voltage also makes it particularly useful for generating bipolar supplies necessary in many analog circuits and systems.

Linear Technology's commitment to high-quality and performance is evident in the LT3580IDD#TRPBF, making it a reliable choice for designers looking for a boost or inverting DC/DC converter solution.
