Products specifications

Categories Integrated Circuits
Manufacturer Linear Technology
Packaging Reel - TR
Status Active
Type DC DC Regulator
Topology Step-Up (Boost)
Internal Switch(s) Yes
Number of Outputs 1
Operating Input Voltage(Min) 2.5V
Maximum Supply Voltage 12V
Channel Output Current 500mA (Switch)
Frequency 1MHz
Dimming PWM
Applications Backlight
Temperature Range - Operating -40°C to 85°C (TJ)
Mounting SMD (SMT)
Case / Package 8-DFN (3x2)
Win Source Part Number 140958-LT3591EDDB#TRPBF
Family Name LT3591
Introduction Date February 14, 2007
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2027
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian LT3591EDDB#TRPBF CAD Model

Description

The LT3591EDDB#TRPBF is a high-performance, adjustable frequency monolithic buck mode DC/DC converter from Linear Technology, designed to drive up to 10 LEDs in series from a wide input range of 3V to 30V. Its flexibility and compact design make it an ideal solution for various applications that require efficient and reliable LED driving capabilities.

Key Features:

  • Wide Input Voltage Range: Operates from 3V to 30V, making it suitable for use in automotive, industrial, and general lighting applications.
  • Internal Switch: The device includes a 36V, 1A internal switch which provides a compact solution with minimal external components.
  • Adjustable Frequency: The switching frequency can be adjusted from 200kHz to 2MHz, allowing optimization for efficiency or external component size.
  • High Efficiency: With efficiencies up to 85%, the LT3591EDDB#TRPBF helps to extend battery life in portable applications.
  • True Color PWM Dimming: Offers wide-range dimming ratios at up to 3000:1, ensuring precise control over LED brightness.
  • Open LED Protection: The device includes open LED protection that prevents overvoltage in case one or more LEDs in a string fail to open.
  • Thermal Protection: The built-in thermal shutdown feature ensures the device operates within safe temperature limits.

Applications:

  • Automotive and Avionic Lighting
  • Industrial Display Backlighting
  • General Purpose LED Illumination
  • Portable Lighting and Flashlights

The LT3591EDDB#TRPBF comes in a small 10-lead (3mm × 3mm) DFN package with an exposed pad for enhanced thermal performance. Its compact size and comprehensive feature set make it an excellent choice for designers looking to create efficient, high-performance LED lighting solutions without compromising on space or functionality.
