Products specifications

Categories Uncategorized
Manufacturer Linear Technology
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 828549-LT6231IS8
Ultra Librarian 3D Model Ultra Librarian LT6231IS8 CAD Model

Description

LT6231IS8 High-Speed Operational Amplifier

The LT6231IS8 from Linear Technology is a high-speed, dual operational amplifier that offers a perfect blend of speed, precision, and low noise performance. Designed with advanced linear technology, this operational amplifier is suitable for a wide range of applications including telecommunications, test equipment, and active filtering.

Key Features:

  • High Gain Bandwidth: The LT6231IS8 boasts an impressive gain bandwidth product of 215MHz, making it ideal for high-frequency signal processing.
  • Low Noise: With a low input noise voltage of 3.9nV/√Hz at 1kHz, this op-amp ensures signal integrity and minimal distortion, which is crucial for precision applications.
  • Fast Slew Rate: A fast slew rate of 135V/µs allows the LT6231IS8 to respond quickly to changes in input signals, providing sharp and accurate output transitions.
  • Low Offset Voltage: The device features a low input offset voltage of 350µV max which enhances the accuracy of the signal processing.
  • Rail-to-Rail Output: The LT6231IS8 can swing its output close to the supply rails, maximizing the dynamic range within a given supply voltage.
  • Single or Dual Supply Operation: It can operate from a single 2.5V to 12.6V supply or dual supplies of ±1.25V to ±6.3V, providing flexibility in various circuit designs.
  • Power Efficient: With a quiescent current of just 3.4mA per amplifier, the LT6231IS8 is power-efficient, making it suitable for battery-powered devices.

Applications:

The LT6231IS8 is versatile and can be used in a variety of applications, including:

  • ADC Buffer
  • Active Filters
  • Fast Amplifiers
  • Video and Cable Drivers
  • Telecommunications Systems
  • Test and Measurement Equipment

Product Specifications:

The LT6231IS8 comes in an 8-lead SOIC package, providing a compact footprint for space-constrained applications. Its operating temperature range from -40°C to 85°C ensures reliable performance in a range of environments.

For designers seeking a high-performance operational amplifier that delivers speed, precision, and low-noise operation, the LT6231IS8 from Linear Technology is an excellent choice that meets the demands of modern electronic circuits.
