LTC1480CS8 - Ultra-Low Power RS485 Transceiver

The LTC1480CS8 is a high-performance RS485 transceiver from Linear Technology, designed to provide efficient communication in industrial, networking, and telecommunication applications. This transceiver stands out for its ultra-low power consumption and its robust design, which ensures reliable data transmission even in harsh environments.

Key Features

• Low Power Operation: The LTC1480CS8 is engineered for power-sensitive applications. It operates with a very low supply current of 120µA for the receiver and 250µA for the transmitter when unloaded, making it an ideal choice for battery-powered and remote systems.
• Half-Duplex Interface: This device supports half-duplex communication, allowing for bidirectional communication over a single pair of wires, which helps reduce the complexity and cost of the wiring.
• High Speed: It is capable of communication rates up to 2.5Mbps, which is suitable for high-speed data transfer requirements.
• Extended Common-Mode Range: The LTC1480CS8 features an extended common-mode range of ±12V, exceeding the requirements of the RS485 standard. This ensures reliable data transmission even in electrically noisy environments.
• Thermal Shutdown Protection: The device includes thermal shutdown protection that disables the transmitter outputs when the die temperature exceeds a preset threshold, preventing damage from overheating.
• Fail-Safe Receiver: The receiver has a fail-safe feature that guarantees a known output if the inputs are open or shorted, enhancing the reliability of the communication system.

Package and Temperature Range

The LTC1480CS8 comes in an 8-lead SOIC package, which is compact and suitable for space-constrained applications. It is designed to operate over the industrial temperature range of -40°C to +85°C, ensuring stable performance across various temperature conditions.

Applications

With its robust feature set, the LTC1480CS8 is an excellent choice for a wide range of applications that require reliable low-power data communications. It is commonly used in:

• Industrial Control Systems
• Building Automation
• Networked Security Systems
• Remote Data Acquisition
• Automotive Networks

Overall, the LTC1480CS8 from Linear Technology is a versatile and reliable transceiver that offers a perfect balance between power efficiency and high-speed performance, making it a top choice for designers looking to develop robust RS485 communication interfaces.
