Products specifications Report Issue?

Category Integrated Circuits(ICs)
Family PMIC - Battery Chargers
Manufacturer Linear Technology
Win Source Part Number 303438-LTC4088EDE
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian LTC4088EDE CAD Model

Description

The LTC4088EDE by Linear Technology is a versatile and advanced power management unit designed to cater to the needs of modern portable devices. This high-efficiency USB power manager with an integrated Li-Ion/Polymer battery charger is capable of automatic power path management, allowing for the seamless operation of a handheld device while simultaneously and efficiently charging the battery.

The LTC4088EDE features a compact, low-profile 14-lead DFN package, making it an ideal solution for space-constrained applications. Its wide input voltage range of 4.25V to 5.5V makes it compatible with standard USB power specifications and ensures adaptability across various USB sources, including USB 2.0, USB 3.0, and high-current wall adapters.

This product stands out with its ability to provide up to 1.5A of continuous charge current for single-cell Li-Ion or Li-Polymer batteries, which is particularly beneficial for devices requiring quick charging times. The LTC4088EDE also incorporates an instant-on feature that ensures system load power is available immediately upon plugging into a USB port, even with a deeply discharged battery.

Moreover, the LTC4088EDE includes a range of safety features, such as automatic recharge, preconditioning for deeply discharged batteries, and a thermistor input for temperature-qualified charging. Its thermal regulation maximizes the charge rate without the risk of overheating, and the charger is designed to automatically terminate upon completion of the charge cycle.

Other notable features include an NTC thermistor interface for temperature-voltage-controlled charging, programmable charge current, and a charge current monitor for gas gauging. The LTC4088EDE also supports a suspend mode that reduces battery drain when the device is not in use.

With its comprehensive feature set and advanced charging capabilities, the LTC4088EDE is a top-tier solution for power management in portable electronic devices, ensuring safety, efficiency, and convenience for both manufacturers and end-users.
