Products specifications

Categories Integrated Circuits
Manufacturer Linear Technology
Packaging Reel - TR
Status Active
Type Source Selector Switch
Polarity P-Channel
Internal Switch(s) Yes
Delay Time - ON 50μs
Delay Time - OFF 4μs
Current - Output (Max) 2.6A
Operating Supply Current 25μA
Supply Voltage - Operating 2.5 V to 5.5 V
Applications Handheld/Mobile Devices
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 10-DFN (3x3)
Win Source Part Number 020666-LTC4413EDD#TRPBF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name LTC4413
Introduction Date November 12, 2004
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian LTC4413EDD#TRPBF CAD Model

Description

Linear Technology LTC4413EDD#TRPBF PowerPath Controller

The LTC4413EDD#TRPBF is an advanced PowerPath controller designed by Linear Technology, now part of Analog Devices, to ensure seamless transition between multiple power sources in dual-supply systems. This intelligent electronic component is packaged in a compact 10-lead DFN with a 3mm x 3mm footprint, making it an ideal choice for space-constrained applications where power supply reliability is critical.

One of the key features of the LTC4413EDD#TRPBF is its low voltage drop, thanks to the internal MOSFET switches that provide a low loss power path. This ensures efficient power delivery and minimizes heat generation, which is crucial for maintaining the performance and longevity of the electronic system. The device also boasts a low quiescent current, which is beneficial for battery-powered applications where power conservation is essential.

The LTC4413EDD#TRPBF has the capability to automatically select the highest priority power source available, whether it's from an AC adapter, a battery, or any other auxiliary source. This prioritization is programmable, allowing designers to tailor the power management to specific system requirements. The controller also provides reverse blocking and thermal protection features to safeguard against potential damage from power source faults or overheating.

With a wide operating voltage range from 2.5V to 5.5V, this PowerPath controller is versatile enough to be used in a variety of applications, including handheld devices, portable media players, and other mobile electronics that require reliable power management. It also supports smooth switchover between sources without causing any interruption to the load, which is essential for maintaining the integrity of sensitive electronic circuits.

In summary, the LTC4413EDD#TRPBF from Linear Technology is a high-performance, dual-input power supply controller that offers efficient power management, seamless source transitions, and robust protection features. Its compact size and advanced functionalities make it an excellent choice for designers looking to enhance the power reliability and efficiency of their systems.
