Products specifications

Manufacturer Linear Technology
Win Source Part Number 1209399-LTM4612V
Manufacturer Homepage www.linear.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian LTM4612V CAD Model

Description

LTM4612V Micro Module Regulator from Linear Technology

The LTM4612V is a high-performance micro module regulator designed by Linear Technology, now part of Analog Devices, that combines top-notch power management capabilities with ease of use. This step-down regulator is an ideal solution for applications that demand efficient power conversion with minimal space requirements.

At the heart of the LTM4612V is a powerful and efficient synchronous buck regulator with an input voltage range of 4.5V to 20V, making it versatile for a wide range of power supply applications. This module is capable of delivering up to 10A of continuous output current, which can be further expanded through parallel operation for applications requiring higher current.

The LTM4612V stands out for its compact design, encapsulated in a low profile (2.8mm) over-molded Land Grid Array (LGA) package measuring 15mm x 15mm. This small footprint allows for convenient placement on densely packed PCBs, making it particularly suitable for space-constrained applications in telecommunications, networking, and industrial systems.

One of the key features of the LTM4612V is its high efficiency, which is essential for thermal management and energy conservation. The regulator's high switching frequency and current mode control enable the use of small external components, further reducing the overall solution size and improving transient response.

The module also includes a host of protection features to ensure reliable operation under various conditions. These include overvoltage, overcurrent, and over-temperature protections, as well as a power good indicator for easy monitoring of the regulator's status.

For design flexibility, the LTM4612V provides adjustable output voltage ranging from 0.8V to 5V, allowing designers to tailor the regulator to their specific requirements. The module is also equipped with frequency synchronization, soft-start, tracking, and output voltage sequencing capabilities, which are critical for managing system power-up and power-down events smoothly.

In summary, the LTM4612V from Linear Technology is a robust and highly integrated micro module regulator that offers a compact, efficient, and flexible power management solution for a wide array of electronic applications.
