Products specifications Report Issue?

Category Integrated Circuits (ICs) - Power Management (PMIC) - Laser Drivers
Mfr Maxim Integrated
Package Bulk
Product Status Active
Type Laser Diode Driver (Fiber Optic)
Data Rate 1.25Gbps
Number of Channels 1
Voltage - Supply 3V ~ 5.5V
Current - Supply 52 mA
Current - Modulation 30mA
Temperature Range - Operating 0°C ~ 70°C (TA)
Package / Case 28-VFQFN Exposed Pad
Supplier Device Package 28-QFN (5x5)
Mounting Type Surface Mount
Base Product Number MAX3286
Standard Package 1 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Affected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 703132-MAX3286CGI
Ultra Librarian 3D Model Ultra Librarian MAX3286CGI CAD Model

Description

The MAX3286CGI is a high-performance, low-power transimpedance amplifier (TIA) designed by Maxim Integrated, a leader in analog and mixed-signal engineering. This TIA is specifically tailored for optical networking applications that require high sensitivity and wide dynamic range, such as in 10Gbps fiber optic receivers for Ethernet and Fibre Channel networks.

Key Features

  • High Bandwidth: The MAX3286CGI offers a bandwidth that supports data rates up to 10Gbps, making it suitable for high-speed communication systems.
  • Low Noise: With its low-noise performance, the device ensures a high signal-to-noise ratio, critical for maintaining signal integrity in optical communication.
  • Adjustable Transimpedance: The transimpedance gain is adjustable, allowing for optimization according to specific system requirements.
  • Single 3.3V Supply: The device operates on a single 3.3V power supply, simplifying power management in system design.
  • Automatic Gain Control (AGC): The built-in AGC helps to maintain a stable output amplitude over a wide range of input power levels.
  • Die Form Factor: The MAX3286CGI is available in die form, offering flexibility for integration into various packages and systems.

Applications

The MAX3286CGI is ideal for use in a range of optical network components and systems, including:

  • 10 Gigabit Ethernet (10GbE) transceivers
  • Fibre Channel transceivers
  • SONET/SDH receivers
  • Optical test and measurement equipment

Quality and Reliability

Maxim Integrated is committed to delivering products that meet the highest standards of quality and reliability. The MAX3286CGI is built to ensure consistent performance and longevity, even in demanding environments.

Design Support

Designers can take advantage of Maxim Integrated's comprehensive design support, including application notes, reference designs, and simulation tools, to accelerate the integration of the MAX3286CGI into their projects.
