Maxim Integrated MAX6413UK29+T Microprocessor Reset Circuit

The Maxim Integrated MAX6413UK29+T is a highly reliable, low-power microprocessor (µP) supervisory circuit designed to monitor power supplies in µP and digital systems. It provides a significant level of system reliability and accuracy required in critical applications. This device is particularly well-suited for portable and battery-powered electronics due to its low power consumption and compact SOT23 packaging.

Key Features

• Voltage Monitoring: The MAX6413UK29+T monitors the system voltage and keeps the µP in reset mode during power-up, power-down, and brownout conditions. It ensures that the µP starts up in a known state every time.
• Reset Threshold: It has a preset reset threshold voltage of 2.93V, optimized for 3V systems, which is crucial for maintaining system stability.
• Low Power Consumption: With its low supply current of only 1.2µA, it is an ideal choice for power-sensitive applications.
• Manual Reset Input: A manual reset input is provided, allowing the user to trigger a reset with an external push-button or logic signal.
• Reset Output: The device offers an active-low, open-drain reset output, which remains asserted for a minimum of 140ms after VCC has risen above the reset threshold, ensuring proper system reset.
• High-Temperature Operation: The MAX6413UK29+T is designed to operate over a wide temperature range of -40°C to +125°C, making it suitable for industrial applications.
• Compact Size: Its small SOT23-5 package saves space on PCBs, a valuable feature for space-constrained designs.

Applications

The MAX6413UK29+T is versatile and can be used in a variety of applications, including:

• Computers and Servers
• Embedded Systems
• Battery-Powered Equipment
• Industrial Controllers
• Portable Consumer Electronics

Overall, the Maxim Integrated MAX6413UK29+T is an essential component for systems that require accurate and reliable monitoring of the supply voltage to ensure proper operation and to protect against data corruption during adverse power conditions. Its combination of features makes it an excellent choice for designers looking to enhance system integrity and prolong battery life in their applications.
