Products specifications

Categories Integrated Circuits
Manufacturer Maxim Integrated
Packaging Tube/Rail
Status Active
Type Simple Reset/Power-On Reset
Number of Voltages Monitored 1
Output Push-Pull, Totem Pole
Reset Active Low
Reset Timeout 140 ms Minimum
Voltage - Threshold 4.65V
Temperature Range - Operating 0°C to 70°C (TA)
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 022077-MAX705CSA+
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian MAX705CSA+ CAD Model

Description

Product Overview: MAX705CSA+

The MAX705CSA+ is a highly reliable and efficient supervisory circuit designed by Maxim Integrated, a leader in analog and mixed-signal products. This compact and robust component is engineered to monitor power supplies in microprocessor and digital systems, providing essential protection and ensuring system stability.

Key Features

  • Power Supply Monitoring: The MAX705CSA+ vigilantly monitors the system's power supply voltage and maintains a watchful eye on the overall health of the system.
  • Manual Reset Input: A manual reset input is available, granting users the ability to trigger a system reset at their discretion, offering additional control and flexibility.
  • Reset Timeout: It features a preset timeout delay, ensuring that the system has adequate time to stabilize before resuming operation after a reset.
  • Low Power Consumption: Designed for power-sensitive applications, this supervisory circuit operates with low power consumption, preserving system resources.
  • Wide Operating Voltage Range: Accommodating a variety of power requirements, the MAX705CSA+ operates over a broad voltage range, making it a versatile choice for diverse applications.
  • Temperature Stability: The integrated circuit is temperature stable, ensuring consistent performance across a wide range of operating conditions.

Applications

The MAX705CSA+ is ideal for use in multiple applications where reliable system monitoring is critical. These applications include:

  • Computers and Servers
  • Embedded Systems
  • Industrial Control Systems
  • Portable/Battery-Powered Equipment

Package and Quality

Enclosed in an 8-pin SOIC package, the MAX705CSA+ is designed for easy integration into system designs without taking up significant board space. Maxim Integrated ensures that each component adheres to stringent quality standards, providing designers and engineers with a dependable solution for their supervisory circuit needs.

With its combination of features, the MAX705CSA+ from Maxim Integrated stands out as a superior choice for system monitoring, offering unmatched reliability and performance that designers can trust.
