Products specifications

Category Discrete Semiconductor Products>Transistors - IGBTs - Modules
Manufacturer Microchip Technology
Packaging Tube
IGBT Type Trench Field Stop
Configuration Single
Voltage - Collector Emitter Breakdown (Max) 1200 V
Current - Collector (Ic) (Max) 215 A
Power - Max 625 W
Vce(on) (Max) @ Vge, Ic 2.1V @ 15V, 150A
Current - Collector Cutoff (Max) 100 µA
Input Capacitance (Cies) @ Vce 9.5 nF @ 25 V
Input Standard
NTC Thermistor No
Temperature Range - Operating -55°C ~ 150°C (TJ)
Mounting Chassis Mount
Case / Package ISOTOP
Supplier Device Package ISOTOP®
Base Product Number APT150
RoHS Status RoHS Compliant
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.29.0095
Other Part Number APT150GN120JMI-ND,APT150GN120JMI
Standard Package 1
Win Source Part Number 1324942-APT150GN120J
Ultra Librarian 3D Model Ultra Librarian APT150GN120J CAD Model

Description

The APT150GN120J is a high-performance, N-channel IGBT (Insulated Gate Bipolar Transistor) designed by Microchip Technology, a leader in the field of smart, connected, and secure embedded control solutions. This IGBT is built for efficiency and power, making it an ideal choice for a range of applications, including motor drives, renewable energy inverters, UPS (Uninterruptible Power Supplies), and switch mode power supplies.

Key Features

  • High Voltage Capability: The APT150GN120J boasts a high voltage rating of 1200V, which allows it to handle significant power levels and makes it suitable for high voltage applications.
  • Low On-Resistance: With a low on-resistance, this IGBT ensures minimal power loss during operation, enhancing overall efficiency.
  • Fast Switching Speed: The device's fast switching capabilities reduce switching losses, which is critical for high-frequency operations.
  • Robust Design: The APT150GN120J is designed to be rugged, with a high tolerance for tough conditions, ensuring reliability and a long operational life.
  • Low Gate Charge: The low gate charge of this IGBT reduces the power required to drive the gate, simplifying the drive circuitry and saving energy.

Applications

The APT150GN120J is versatile and can be used in various high power applications. Its robustness and efficiency make it particularly well-suited for:

  • Industrial Motor Drives
  • Renewable Energy Inverters
  • Uninterruptible Power Supplies (UPS)
  • Power Factor Correction Circuits
  • Switch Mode Power Supplies (SMPS)

Product Specifications

Parameter Value Collector-Emitter Voltage (V<sub>ces) 1200V Collector Current (I<sub>c) 150A Power Dissipation (P<sub>d) 830W Operating Temperature Range -55°C to +150°C Package Type SP4

With its combination of high voltage capability, efficiency, and speed, the APT150GN120J from Microchip Technology is a reliable and powerful component for your high-performance power management solutions.
