Products specifications

Category Discrete Semiconductor Products>Diodes - Rectifiers - Arrays
Manufacturer Microchip Technology
Packaging Tube
Diode Configuration 1 Pair Common Cathode
Diode Type Standard
Voltage - DC Reverse (Vr) (Max) 400 V
Current - Average Rectified (Io) (per Diode) 60A
Voltage - Forward (Vf) (Max) @ If 1.5 V @ 60 A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr) 37 ns
Current - Reverse Leakage @ Vr 250 µA @ 400 V
Operating Temperature - Junction -55°C ~ 175°C
Mounting Through Hole
Case / Package TO-264-3, TO-264AA
Supplier Device Package TO-264 [L]
Base Product Number APT60D40
RoHS Status RoHS Compliant
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Standard Package 1
Win Source Part Number 1325750-APT60D40LCTG
Ultra Librarian 3D Model Ultra Librarian APT60D40LCTG CAD Model

Description

Introducing the APT60D40LCTG Power MOSFET by Microchip Technology

Microchip Technology, a leading provider of microcontroller, mixed-signal, analog, and Flash-IP solutions, offers the APT60D40LCTG Power MOSFET as part of its extensive semiconductor product line. This high-performance component is designed to meet the demanding requirements of a wide range of power applications.

The APT60D40LCTG is a state-of-the-art silicon carbide (SiC) Power MOSFET that boasts a 600V drain-to-source breakdown voltage (V<sub>DS), making it an ideal choice for high-voltage power systems. With a continuous drain current (I<sub>D) of 40A at 25°C, this MOSFET can handle significant power without overheating, thanks to its low on-resistance (R<sub>DS(on)) of 40mΩ. This combination of high voltage and current handling capabilities, along with low on-resistance, ensures high efficiency and reliability in power conversion applications.

The APT60D40LCTG features a fast switching speed and a rugged, avalanche-rated design. The fast switching capability reduces switching losses, which is crucial for applications such as switch-mode power supplies, motor drives, and power inverters. The avalanche rating provides an additional layer of protection against unexpected voltage spikes, ensuring long-term reliability and stability in harsh electrical environments.

Moreover, the APT60D40LCTG comes in a TO-247 package, which is widely recognized for its excellent thermal performance. The package design ensures efficient heat dissipation, further contributing to the device's robustness and longevity. This makes the MOSFET suitable for high-power density applications where space is at a premium, and thermal management is critical.

Whether you're designing for industrial, automotive, or consumer electronics, the APT60D40LCTG Power MOSFET from Microchip Technology offers the performance and durability needed to create products that stand out in today's competitive market. With its combination of high-voltage capability, low on-resistance, fast switching, and robust package, the APT60D40LCTG is a superior choice for designers looking to optimize their power systems for efficiency and reliability.
