Products specifications

Category Discrete Semiconductor Products - Diodes - Rectifiers - Diode Arrays
Mfr Microchip Technology
Package Tube
Product Status Active
Diode Configuration 1 Pair Common Cathode
Technology Standard
Voltage - DC Reverse (Vr) (Max) 600 V
Current - Average Rectified (Io) (per Diode) 60A
Voltage - Forward (Vf) (Max) @ If 1.8 V @ 60 A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr) 130 ns
Current - Reverse Leakage @ Vr 250 µA @ 600 V
Operating Temperature - Junction -55°C ~ 175°C
Mounting Type Through Hole
Package / Case TO-264-3, TO-264AA
Supplier Device Package TO-264 [L]
Base Product Number APT60
Standard Package 1 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 564181-APT60D60LCTG
Ultra Librarian 3D Model Ultra Librarian APT60D60LCTG CAD Model

Description

Product Overview: APT60D60LCTG from Microchip Technology

The APT60D60LCTG is a high-performance power device engineered by the renowned Microchip Technology, a leader in the field of microcontroller and analog semiconductors. This power device is a state-of-the-art silicon carbide (SiC) Schottky diode designed to provide efficient power conversion with minimal losses, making it an ideal choice for a wide range of applications.

Key Features

  • Voltage Rating: The APT60D60LCTG boasts a 600V voltage rating, which allows it to handle high voltage applications with ease.
  • Current Capacity: With a 60A current rating, this diode can support high current flows, making it suitable for power-intensive tasks.
  • Low Forward Voltage Drop: The low forward voltage drop characteristic of this SiC Schottky diode ensures that power loss is minimized during operation, leading to increased efficiency.
  • High-Temperature Operation: It is designed to perform reliably in high-temperature environments, which is critical for applications that are exposed to extreme conditions.
  • Fast Switching Speed: The fast switching capabilities of the APT60D60LCTG minimize energy wastage during the transition between on and off states, contributing to its overall efficiency.
  • Zero Reverse Recovery Charge: The diode's zero reverse recovery charge is essential for reducing switching losses and improving the performance of power conversion systems.

Applications

The APT60D60LCTG from Microchip Technology is a versatile component suitable for numerous applications, including:

  • Power Supply Units (PSUs)
  • Electric Vehicle (EV) Charging Stations
  • Photovoltaic (Solar) Inverters
  • Uninterruptible Power Supplies (UPS)
  • High-Efficiency Power Converters
  • Motor Drives

Reliability and Quality

Microchip Technology is committed to delivering products that meet the highest standards of quality and reliability. The APT60D60LCTG is no exception, with rigorous testing and quality control measures in place to ensure that it performs to the expectations of even the most demanding applications.

In summary, the APT60D60LCTG SiC Schottky diode is a cutting-edge component that offers efficiency, durability, and high performance, making it a smart choice for designers and engineers looking to enhance their power conversion systems.
