Products specifications

Category Integrated Circuits (ICs) - Embedded - Microcontrollers
Mfr Microchip Technology
Series AVR® ATtiny
Package Tube
Product Status Active
Programmable Verified
Core Processor AVR
Core Size 8-Bit
Speed 20MHz
Connectivity USI
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Number of I/O 16
Program Memory Size 4KB (2K x 16)
Program Memory Type FLASH
EEPROM Size 256 x 8
RAM Size 256 x 8
Voltage - Supply (Vcc/Vdd) 1.8V ~ 5.5V
Data Converters A/D 11x10b
Oscillator Type Internal
Temperature Range - Operating -40°C ~ 85°C (TA)
Mounting Type Surface Mount
Package / Case 20-SOIC (0.295", 7.50mm Width)
Supplier Device Package 20-SOIC
Base Product Number ATTINY461
Standard Package 37 pcs
MSL Level 2 (1 Year)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.31.0001
Win Source Part Number 566964-ATTINY461A-SU
Ultra Librarian 3D Model Ultra Librarian ATTINY461A-SU CAD Model

Description

Microchip Technology's ATTINY461A-SU Microcontroller

The ATTINY461A-SU is a high-performance, low-power AVR 8-bit microcontroller from Microchip Technology, which offers a perfect blend of power efficiency and processing capability. This compact microcontroller is ideal for a wide range of applications, including industrial control, consumer electronics, and sensor systems, thanks to its rich feature set and flexibility.

Key Features:

  • Advanced RISC Architecture: The ATTINY461A-SU is equipped with 120 powerful instructions, most of which are executed in a single clock cycle. This allows for a balanced approach to speed and power consumption, achieving throughputs approaching 1 MIPS per MHz.
  • Memory: It boasts 4KB of in-system self-programmable flash, 256B EEPROM, and 256B SRAM, providing ample space for application code and data storage.
  • Power Efficiency: With its picoPower technology, it is designed for operation in an extended range of power supplies from 1.8V to 5.5V, ensuring power efficiency and reliability for battery-operated applications.
  • Peripheral Features: The microcontroller includes a variety of peripherals such as an 8-channel 10-bit A/D converter, a programmable watchdog timer with internal oscillator, and a range of timers/counters with PWM capabilities.
  • I/O and Packages: It provides 16 general-purpose I/O lines and comes in a 20-lead SOIC package, making it easy to integrate into a variety of PCB designs.
  • Speed Grades: The ATTINY461A-SU operates at clock speeds up to 20MHz, allowing for swift processing and response times.

Applications:

The versatility of the ATTINY461A-SU makes it suitable for many applications, including but not limited to:

  • Automotive systems
  • Home automation and security
  • Battery management
  • Small appliances
  • Wearable devices

Why Choose ATTINY461A-SU:

If you're looking for a microcontroller that balances cost, performance, and power consumption, the ATTINY461A-SU is an excellent choice. Its robust architecture, combined with Microchip's reputation for quality and support, makes it a reliable cornerstone for any microcontroller-based project or product.
