Products specifications

Manufacturer Microchip Technology
Packaging Tray
Protocol Ethernet
Function Controller
Interface SPI
Standards 10/100 Base-FX/T/TX PHY
Supply Voltage (V) 1.8V ~ 3.3V
Temperature Range - Operating -40°C ~ 85°C
Manufacturer Package 64-VFQFN Exposed Pad
Supplier Device Package 64-QFN (9x9)
Part Number Series LAN9252
Manufacturer Pack Quantity 260
MSL Level 3 (168 Hours)
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 809237-LAN9252I/ML
Ultra Librarian 3D Model Ultra Librarian LAN9252I/ML CAD Model

Description

Microchip Technology's LAN9252I/ML - High-Performance EtherCAT Slave Controller

Microchip Technology's LAN9252I/ML is a feature-rich, stand-alone EtherCAT slave controller optimized for industrial automation and control system applications. This powerful device is designed to function with minimal dependency on external components and is tailored to facilitate rapid communication and processing, making it an ideal solution for high-speed automation networks.

Key Features:

  • Integrated Dual PHYs: The LAN9252I/ML comes with dual integrated Ethernet PHYs, which simplifies design and reduces the overall bill of materials, while offering robust communication capabilities.
  • Flexible Interface Options: It supports various host interface options including SPI, High-Speed SPI, and parallel interfaces, providing versatility for different system architectures.
  • Synchronization Precision: The device includes support for Distributed Clocks (DC), enabling precise synchronization with other nodes in the EtherCAT network, which is critical for coordinated motion control and time-sensitive applications.
  • Extended Temperature Range: With an industrial temperature range of -40°C to +85°C, the LAN9252I/ML is designed to withstand harsh operating environments, ensuring reliable performance under extreme conditions.

Advanced Capabilities:

The LAN9252I/ML boasts an array of advanced features such as Fast Ethernet communication, 4Kbytes of Dual-Port RAM, and 3 Fieldbus Memory Management Units (FMMUs). Its efficient architecture allows for the mapping of device memory to the EtherCAT process data interface, facilitating rapid data exchanges with the host microcontroller.

Application Areas:

Due to its high-speed performance and reliability, the LAN9252I/ML is well-suited for a broad range of industrial applications, including:

  • Robotics and automated manufacturing systems
  • Motion control and drives
  • Industrial I/O modules
  • Sensor and actuator integration

Overall, Microchip's LAN9252I/ML EtherCAT slave controller is a robust, high-performance solution that offers designers a compact, efficient, and cost-effective option for integrating EtherCAT connectivity into their industrial automation projects.
