Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Estimated Pruduction Lead Time 3 Weeks
Features I/O Expander 16 I²C 3.4 MHz 24-SSOP
Manufacturer Microchip Technology
Package Tube
Number of I/O 16
Operating Temperature Range -40°C ~ 125°C
Mounting Surface Mount
Package 24-SSOP (0.209", 5.30mm Width)
Case / Package 24-SSOP
Family Name MCP23018
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Quantity per package 59
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 884145-MCP23018-E/SS
Ultra Librarian 3D Model Ultra Librarian MCP23018-E/SS CAD Model

Description

Microchip Technology MCP23018-E/SS

The MCP23018-E/SS is a highly versatile, 16-bit I/O expander from Microchip Technology, designed to provide additional input/output capability to an I2C bus or SPI interface. This integrated circuit is an ideal solution for applications where additional I/Os are necessary without the need for a larger microcontroller or processor. Its compact SSOP-28 (Shrink Small Outline Package) makes it suitable for space-constrained applications.

At the heart of the MCP23018-E/SS is an array of 16 I/O ports that can be individually configured as either an input or output, providing a flexible interface for a wide range of peripheral devices. Each I/O port can be accessed through a simple serial interface, compatible with the I2C protocol, which allows for easy integration with most microcontrollers and processors on the market.

One of the key features of the MCP23018-E/SS is its built-in interrupt output which can be configured to alert the host microcontroller when an input state has changed, thus reducing the need for constant polling and allowing for more efficient power management in battery-operated devices. Additionally, the device supports multiple address pins, enabling the connection of up to eight devices on the same I2C bus without address conflicts, providing up to 128 additional I/Os.

The MCP23018-E/SS also comes with robust protection features, including high-current sink/source capability, high-voltage I/O protection, and ESD protection. These features ensure reliable operation in harsh environments and contribute to the overall durability of the end product. The device operates over a wide voltage range and has a temperature range suitable for commercial and industrial applications.

Whether you're designing a complex human-machine interface, expanding the I/O capabilities of a small microcontroller, or simply needing more pins for sensors and actuators, the Microchip MCP23018-E/SS provides a cost-effective, reliable solution for your I/O expansion needs.

For detailed technical specifications, application notes, and support resources, visit the Microchip Technology website or consult the MCP23018-E/SS datasheet.
