Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Tube/Rail
Status Active
Amplifier Type General Purpose
Number of Circuits 1
Output Type Rail-to-Rail
Slew Rate 0.004 V/μs
Gain Bandwidth Product (GBP) 10kHz
Current - Input Bias 1pA
Voltage - Input Offset 150μV
Operating Supply Current 900nA
Channel Output Current 23mA
Supply Voltage - Operating 1.8 V to 5.5 V
Temperature Range - Operating -40°C to 125°C
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 1075151-MCP6031-E/SN
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian MCP6031-E/SN CAD Model

Description

The MCP6031-E/SN from Microchip Technology is a high-precision operational amplifier (op-amp) that offers advanced features and robust performance for a wide range of applications. This op-amp is part of Microchip's family of products designed to provide low power consumption without sacrificing performance, making it an ideal choice for battery-powered devices and energy-sensitive applications.

Key Features:

  • Low Power Consumption: With a quiescent current of just 900 nA, the MCP6031-E/SN is optimized for battery-operated devices, ensuring extended battery life and efficiency.
  • High Precision: This op-amp boasts a low offset voltage of just 150 µV, making it suitable for applications that require high accuracy and stability.
  • Extended Temperature Range: The device operates over an industrial temperature range of -40°C to +125°C, which ensures reliable performance in harsh environments.
  • Gain Bandwidth Product: With a GBWP of 10 kHz, the MCP6031-E/SN provides a balance between speed and power consumption, suitable for low-frequency applications.
  • Rail-to-Rail Input/Output: The rail-to-rail input and output operation allows for a wide dynamic range, making it versatile for various signal conditioning tasks.

Applications:

The MCP6031-E/SN is designed for a multitude of applications, including:

  • Portable and battery-powered equipment
  • Sensor interfacing and signal conditioning
  • Analog filters
  • Data acquisition systems
  • Medical devices
  • Automotive control systems

Package and Quality:

The MCP6031-E/SN comes in an 8-pin SOIC (Small Outline Integrated Circuit) package, which is ideal for space-constrained applications. It also meets the stringent quality standards set by Microchip Technology, ensuring reliability and performance consistency across various conditions.

In summary, the MCP6031-E/SN from Microchip Technology is a versatile, high-precision operational amplifier that offers an excellent balance of power efficiency and accuracy, suitable for a wide range of applications in the industrial, automotive, and consumer electronics sectors.
