Products specifications

Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Cut Reel
Type Linear
Internal Switch(s) Yes
Number of Outputs 6
Operating Input Voltage(Min) 3V
Maximum Supply Voltage 5.5V
Channel Output Current 20mA
Dimming Single-Wire
Applications Backlight, Camera Flash
Temperature Range - Operating -40°C to 125°C (TJ)
Mounting SMD (SMT)
Case / Package 10-TMLF (2x2)
Win Source Part Number 098387-MIC2844AYMT-TR
Ultra Librarian 3D Model Ultra Librarian MIC2844AYMT-TR CAD Model

Description

Introducing the MIC2844AYMT-TR from Microchip Technology

Microchip Technology's MIC2844AYMT-TR is a compact, high-efficiency LED driver, designed to meet the needs of space-constrained and power-sensitive applications. This versatile and reliable integrated circuit is perfect for a wide range of uses, from general lighting to portable devices that require consistent and controlled illumination.

Key Features

  • Integrated 4-Channel LED Driver: The MIC2844AYMT-TR is equipped with four independent LED channels, allowing for precise control of multiple LEDs simultaneously.
  • High Efficiency: With its high-efficiency design, this driver ensures minimal power loss and maximizes battery life in portable applications.
  • Dimming Capability: It supports both analog and digital dimming, providing flexibility for brightness control to suit any user preference or application requirement.
  • Thermal Protection: The built-in thermal shutdown feature protects the device and the LEDs from overheating, ensuring a long operational life and consistent performance.

Applications

The MIC2844AYMT-TR is ideal for a variety of lighting applications, including:

  • Smartphone and tablet backlighting
  • LED status or indicator lights
  • Portable and battery-powered equipment
  • General-purpose LED illumination

Technical Specifications

  • Input Voltage Range: 2.7V to 5.5V, accommodating a variety of power sources.
  • Output Current: Up to 30mA per channel, providing sufficient power for a wide array of LED configurations.
  • Small Footprint: The device is offered in a compact 12-pin 3mm x 3mm TQFN package, making it perfect for space-limited designs.
  • Temperature Range: Operating temperature range from -40°C to +85°C, ensuring reliable performance in diverse environments.

The MIC2844AYMT-TR is not only a testament to Microchip Technology's commitment to innovation but also a solution that addresses the growing demand for energy-efficient and miniaturized LED drivers. With its robust feature set and adaptable design, it stands out as a top choice for developers and manufacturers looking to enhance their lighting solutions.
