Products specifications

Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Reel - TR
Status Active
Driven Configuration High-Side or Low-Side
Channel Type Single
Number of Drivers 1
Gate Type N-Channel MOSFET
Supply Voltage - Operating 2.75 V to 30 V
Logic Voltage - VIL, VIH 0.8V, 2V
Input Type Non-Inverting
Temperature Range - Operating -40°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 140415-MIC5014YM-TR
Ultra Librarian 3D Model Ultra Librarian MIC5014YM-TR CAD Model

Description

Product Overview: MIC5014YM-TR by Microchip Technology

The MIC5014YM-TR is a high-performance, reliable integrated circuit designed by Microchip Technology, a leading provider of smart, connected, and secure embedded control solutions. This particular product is a part of Microchip's extensive line of power management solutions, specifically tailored to meet the rigorous demands of today's advanced electronic systems.

The MIC5014YM-TR functions as a high-side MOSFET driver, capable of operating with supply voltages from 4.5V to 18V. Its robust design ensures efficient control of high-side N-channel power MOSFETs, making it a versatile choice for a variety of applications such as automotive, industrial control, and automation systems.

One of the standout features of the MIC5014YM-TR is its low power consumption. It boasts a quiescent current of just 125µA, which is particularly beneficial in battery-operated devices where power efficiency is crucial. Furthermore, the device's TTL/CMOS compatible input thresholds ensure easy interfacing with a wide range of control logic levels.

The MIC5014YM-TR comes in a compact 8-pin SOIC package, which is not only space-saving but also offers enhanced thermal performance. The package is offered in Tape & Reel (TR) format, making it suitable for automated assembly processes and high-volume production.

Safety features are integral to the MIC5014YM-TR design. It includes built-in protection against overcurrent conditions, which safeguards the device and the system it controls. Additionally, the driver is equipped with an automatic shutdown feature that activates in response to fault conditions, further enhancing its reliability.

In summary, the MIC5014YM-TR from Microchip Technology is a high-side power MOSFET driver that combines efficiency, versatility, and reliability. Its compatibility with various supply voltages, low power consumption, and robust protection features make it an excellent choice for designers looking to optimize their power management systems.
