Products specifications

Categories Integrated Circuits (ICs)
Manufacturer Microchip Technology
Series PIC XLP 18K
Packaging Tray
Core Processor PIC
Core Size 8-Bit
Speed 48MHz
Connectivity I2C, SPI, UART/USART
Peripherals Brown-out Detect/Reset, HLVD, POR, PWM, WDT
Number of I/O 35
Program Memory Size 64KB (32K x 16)
Program Memory Type FLASH
EEPROM Size 1K x 8
RAM Size 3.8K x 8
Supply Voltage 2.3 V ~ 5.5 V
Data Converters A/D 30x10b
Oscillator Type Internal
Operating Temperature Range -40°C ~ 125°C (TA)
Package 44-TQFP
Manufacturer Package 44-TQFP (10x10)
Win Source Part Number 792109-PIC18F46K22-E/PT
Popularity Medium
Supply and Demand Status Limited
Family Name PIC18F46K22
Introduction Date February 01, 2010
ECCN 3A991.a.2
Country of Origin Thailand
Halogen Free Compliant
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian PIC18F46K22-E/PT CAD Model

Description

Product Overview: PIC18F46K22-E/PT

The PIC18F46K22-E/PT is a high-performance microcontroller unit (MCU) from the reputable semiconductor manufacturer, Microchip Technology. This MCU is part of the PIC18F K22 family, which is well-known for its robust design, versatility, and efficiency in a wide range of applications. The PIC18F46K22-E/PT is an ideal choice for developers looking for a reliable and powerful microcontroller with advanced features and extensive peripheral support.

Key Features:

  • Core Processor: PIC
  • Core Size: 8-Bit
  • Speed: Up to 64MHz
  • Number of I/O: 36
  • Program Memory Size: 64KB (32K x 16)
  • EEPROM Size: 1KB
  • RAM Size: 3.8KB
  • Data Converters: 12-bit A/D 28x, D/A 2x
  • Peripherals: Brown-out Detect/Reset, POR, PWM, WDT
  • Connectivity: I2C, SPI, UART/USART
  • Supply Voltage: 1.8 V ~ 5.5 V
  • Operating Temperature: -40°C ~ 85°C (TA)
  • Package / Case: 44-TQFP

Advanced Integration:

The PIC18F46K22-E/PT is equipped with a rich set of integrated peripherals, including multiple communication interfaces such as I2C, SPI, and UART/USART, which enable seamless integration with other electronic components and systems. The inclusion of 12-bit Analog-to-Digital Converters (ADCs) and Digital-to-Analog Converters (DACs) allows for precise sensor interfacing and analog signal processing, making it suitable for complex tasks in industrial, automotive, and consumer electronics.

Power Management:

With its wide operating voltage range and power-saving features like Power-on Reset (POR), Brown-out Reset (BOR), and Watchdog Timer (WDT), the PIC18F46K22-E/PT ensures reliable operation under varying power conditions. These features contribute to the MCU's robustness and make it an excellent choice for battery-operated devices and power-sensitive applications.

Design Flexibility:

Designers and engineers will appreciate the flexibility that the PIC18F46K22-E/PT offers. The MCU's extensive I/O capabilities, along with its programmable memory and various timers, provide a solid foundation for creating sophisticated and customized applications. Whether it's for automation systems, IoT devices, or consumer electronics, this microcontroller adapts to the specific needs of the project.

Conclusion:

The PIC18F46K22-E/PT from Microchip Technology is a versatile and powerful MCU that delivers performance, efficiency, and reliability. Its comprehensive feature set and adaptability make it a top choice for designers looking to push the boundaries of what's possible with modern microcontroller technology.
