Products specifications

Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Tube/Rail
Status Active
Driven Configuration Low-Side
Channel Type Independent
Number of Drivers 2
Gate Type N-Channel, P-Channel MOSFET
Supply Voltage - Operating 4.5 V to 18 V
Logic Voltage - VIL, VIH 0.8V, 2.4V
Current - Peak Output (Source, Sink) 1.5A, 1.5A
Input Type Inverting, Non-Inverting
Rise and Fall Time 25ns, 25ns
Temperature Range - Operating -40°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 092388-TC4428AEOA
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian TC4428AEOA CAD Model

Description

Product Overview: TC4428AEOA from Microchip Technology

The TC4428AEOA is a robust, high-speed, dual-channel MOSFET driver designed and manufactured by Microchip Technology. This powerful component is engineered to convert TTL or CMOS input logic levels to a higher voltage and current output signal, making it an ideal choice for driving large power MOSFETs and IGBTs in a variety of applications.

Key Features

  • High Peak Output Current: Each driver channel of the TC4428AEOA can deliver up to 1.5A, ensuring strong drive capability for power-intensive applications.
  • Wide Operating Range: The device operates over a voltage range of 4.5V to 18V, accommodating a variety of power systems and ensuring versatility across different use cases.
  • Matched Rise and Fall Times: With matched rise and fall times, this driver provides consistent switching performance, which is crucial for timing-sensitive applications.
  • High Noise Immunity: Inputs are designed to be highly resistant to latch-up and can tolerate up to 1.5V of negative swing below ground, providing reliability in noisy environments.

Applications

The TC4428AEOA is well-suited for a range of applications, including but not limited to:

  • Switch Mode Power Supplies (SMPS)
  • DC-to-DC Converters
  • Motor Control Circuits
  • Pulse Transformer Drive
  • Line Drivers

Package and Quality

Packaged in a 8-pin SOIC outline, the TC4428AEOA offers a compact solution for space-constrained applications. Microchip Technology's commitment to quality ensures that this driver meets stringent industry standards for performance and reliability.

Conclusion

In summary, the TC4428AEOA from Microchip Technology is a high-performance, dual-channel MOSFET driver that offers a combination of high-speed operation, robust output drive, and noise immunity. Its versatility and reliability make it an excellent choice for designers looking to enhance the efficiency and performance of their power management systems.
