Products specifications

Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Tube/Rail
Status Active
Driven Configuration Low-Side
Channel Type Independent
Number of Drivers 2
Gate Type N-Channel, P-Channel MOSFET
Supply Voltage - Operating 4.5 V to 18 V
Logic Voltage - VIL, VIH 0.8V, 2.4V
Current - Peak Output (Source, Sink) 1.5A, 1.5A
Input Type Inverting, Non-Inverting
Rise and Fall Time 25ns, 25ns
Temperature Range - Operating -40°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 031940-TC4428COA
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian TC4428COA CAD Model

Description

The TC4428COA is a robust, high-performance dual-channel MOSFET driver manufactured by Microchip Technology, designed to accommodate a wide range of power management and control applications. This versatile driver can convert TTL or CMOS input logic levels to a higher voltage and current output, with each driver independently capable of sourcing or sinking up to 1.5A of current.

Key Features:

  • Dual Non-Inverting Channels: The TC4428COA features two non-inverting drivers that ensure a direct translation from input to output, maintaining signal integrity.
  • High Peak Output Current: Each output is capable of driving 1.5A, making it suitable for driving large capacitive loads with rapid switching times.
  • Wide Operating Range: The device operates over a voltage range of 4.5V to 18V, providing the flexibility needed for various applications.
  • High-Speed Operation: With a typical delay time of 55ns, the TC4428COA is designed for applications that require fast switching and precise timing.
  • Latch-Up Protected: The driver is latch-up protected for up to 500mA of reverse current, ensuring device safety and reliability under extreme conditions.
  • Matched Rise and Fall Times: The device offers matched rise and fall times, which minimizes the switching noise and reduces the likelihood of cross-conduction.
  • Low Supply Current: With a quiescent current of 3mA, the TC4428COA conserves power in steady state, making it ideal for power-sensitive applications.
  • Extended Temperature Range: The device is operational over an industrial temperature range of -40°C to +85°C, ensuring performance in harsh environments.

Applications:

The TC4428COA is suitable for a variety of applications, including but not limited to:

  • Power MOSFET Gate Drivers
  • Motor Controllers
  • Line Drivers
  • Switch Mode Power Supplies (SMPS)
  • Pulse Transformers

With its robust design and high functionality, the TC4428COA from Microchip Technology is an ideal choice for engineers and designers looking for a reliable dual-channel MOSFET driver that can handle high-power and high-speed requirements with ease.
