Products specifications

Category RF and Wireless - RF Power Dividers/Splitters
Mfr Mini-Circuits
Package Tape & Reel
Product Status Active
Insertion Loss 0.8dB
Frequency 800 MHz ~ 2.1 GHz
Specifications Isolation (Min) 17dB, 1.2 VSWR (Typ), 4° Imbalance (Max)
Size / Dimension 0.118" L x 0.118" W x 0.039" H (3.00mm x 3.00mm x 0.99mm)
Package / Case 12-VQFN Exposed Pad
Standard Package 2,000 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 137670-GP2S+
Ultra Librarian 3D Model Ultra Librarian GP2S+ CAD Model

Description

The Mini-Circuits RF Power Divider/Splitter, with Win Source Part Number 137670-GP2S+, is a compact and efficient component for RF and wireless applications. It falls under the category of RF Power Dividers/Splitters and offers excellent isolation, with a minimum of 17dB. The VSWR (Voltage Standing Wave Ratio) is typically 1.2, ensuring low signal loss and efficient power distribution. The size of this power divider/splitter is 0.118" L x 0.118" W x 0.039" H (3.00mm x 3.00mm x 0.99mm), making it suitable for compact designs. It comes in a 12-VQFN Exposed Pad package, which provides easy installation and thermal management. The Mini-Circuits RF Power Divider/Splitter is an active product, readily available for purchase. With its high performance and reliability, it is an ideal choice for RF and wireless systems.
