The Molex 36644-0004 is a Micro-Fit 3.0 receptacle housing designed for wire-to-wire and wire-to-board connections. This housing is part of the Micro-Fit 3.0 connector system, known for its compact size and high current carrying capabilities, making it suitable for a wide range of applications.

Applications

• Power supplies
• Consumer electronics
• Automotive applications (lighting, sensors)
• Industrial control systems
• Data communications equipment

Features

• Compact design: Micro-Fit 3.0 connectors offer a small footprint, saving space on the PCB or within the application.
• Positive locking: Provides a secure connection, preventing accidental disconnections due to vibration or movement.
• Fully polarized housing: Ensures correct mating, preventing damage to the connector or equipment.
• Terminal Position Assurance (TPA): Offers an additional layer of security by ensuring that the terminals are fully seated and locked in the housing.
• Durable material: Constructed from high-quality materials to withstand harsh environments and provide long-lasting performance.

Benefits

• Reliable connection: The positive locking and TPA features ensure a secure and stable electrical connection.
• Space-saving: The compact design allows for use in applications where space is limited.
• Easy to use: The polarized housing and intuitive design simplify the assembly process.
• Versatile: Suitable for a wide range of applications due to its high current carrying capacity and compact size.
• Cost-effective: Offers a balance of performance and price, making it a competitive solution for various connectivity needs.

Additional Details

The 36644-0004 receptacle housing is typically used with Micro-Fit 3.0 series terminals. It's crucial to select the appropriate terminals and wire gauge to ensure optimal performance and compliance with safety standards. The housing is designed to meet industry standards for flammability and environmental protection. Refer to the Molex datasheet for complete specifications, including voltage and current ratings, operating temperature range, and mating connector information.
