Same model may have multiple batches, images only for reference.
501940-0307 Real Image
Same model may have multiple batches, images only for reference.

501940-0307

Part No 501940-0307
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description 1.0W/BWAFERASSYST1-ROW+LOCK3CKTE  /  Connector Header position
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Male Pins
Mfr Molex
Series *
Package Tape & Reel (TR)
RoHS Status RoHS non-compliant
MSL Level Vendor Undefined
REACH Status REACH info available upon request
ECCN EAR99
HTSUS 8536.69.4040
Other Names 2266-501940-0307TR
Standard Package 1
Win Source Part Number 1002625-501940-0307
Ultra Librarian 3D Model Ultra Librarian 501940-0307 CAD Model

Description

The 501940-0307 is a male pin rectangular connector header designed to provide a reliable connection for various electronic devices.

  • Packaging: Tape & Reel
  • Package Quantity: 1
  • RoHS Compliant: Non-Compliant
  • HTSUS Code: 8536.69.4040
  • Ideal For: Various electronic devices that require a male pin rectangular connector header
