502584-0670 Real Image
Same model may have multiple batches, images only for reference.

502584-0670

Part No 502584-0670
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Conn Wire to Board RCP 6 POS 1.5mm Solder ST SMD CLIK-Mate™ T/R
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Color Beige
Connector Type Center Strip Contact, Receptacle
Contact Gender Female
Contact Material Copper
Contact Plating Tin
Country of Origin JP
Current Rating 2 A
Depth 6.35 mm
Fastening Type Latch
Gender Receptacle
Glow Wire Compliant Non-compliant
Housing Color Beige
Housing Material Resin
Length 13.3 mm
Max Operating Temperature 85 °C
Min Operating Temperature -25 °C
Mount Surface Mount
Number of Circuits 6
Number of Contacts 6
Number of Pins 6
Number of Positions 6
Number of Rows 1
Orientation Vertical
Packaging Cut Tape
Pitch 1.5 mm
Radiation Hardening No
REACH SVHC Unknown
RoHS Compliant
Termination Solder
Voltage Rating 100 V
Win Source Part Number 1210284-502584-0670
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian 502584-0670 CAD Model

Description

The 1210284-502584-0670 is a circular connector housing manufactured by Molex, LLC.

  • Positions: 6-position center strip contact receptacle
  • Pitch: 1.5 mm
  • Contact Material: Copper
  • Voltage Rating: 100 V
  • Current Rating: 2 A
  • RoHS Compliant: Yes
  • Housing Color: Beige
