76825-0002 Real Image
Same model may have multiple batches, images only for reference.

76825-0002

Part No 76825-0002
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Mega-Fit Right-Angle Header, 2 Circuits, Tin (Sn) Plating, UL 94 V-0, Glow-Wire Capable, Tray
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Color Black
Contact Material Copper
Contact Plating Tin
Country of Origin CN
Current Rating 23.5 A
Gender Male
Height 14.78 mm
Max Operating Temperature 105 °C
Min Operating Temperature -40 °C
Number of Circuits 2
Number of Contacts 2
Number of Pins 2
Number of Rows 2
Orientation Right Angle
Pitch 5.7 mm
Plating Tin
REACH SVHC Unknown
RoHS Compliant
Termination Through Hole
Voltage Rating 600 V
Win Source Part Number 1228116-76825-0002
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian 76825-0002 CAD Model

Description

The Molex 1228116-76825-0002 is a circular connector housing that has 2 contacts and 2 pins.

  • Contacts: 2
  • Pins: 2
  • Pitch: 5.7 mm
  • Termination: Through-Hole
  • Material: Tin-Plated Copper
  • Color: Black
  • Voltage Rating: 600 V
  • Current Rating: 23.5 A
  • RoHS Compliant: Yes
  • Height: 14.78 mm
