90130-1226 Real Image
Same model may have multiple batches, images only for reference.

90130-1226

Part No 90130-1226
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Conn Ejector Header HDR 26 POS 2.54mm Solder ST Top Entry Thru-Hole Tray
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Color Black
Connector Type Male Pin
Contact Gender Male
Contact Material Brass
Contact Mating Length 6.7564 mm
Contact Plating Gold
Contact Resistance 20 mΩ
Country of Origin SK
Current Rating 3 A
Gender Male
Glow Wire Compliant Non-compliant
Housing Color Black
Housing Material Polyester
Insulation Resistance 5 GΩ
Lead Free Yes
Lead Pitch 2.54 mm
Material Glass, Polyester
Maximum Operating Temperature 125 °C
Max Voltage Rating (DC) 350.35 kV
Min Operating Temperature -55 °C
Mount Through Hole
Number of Circuits 26
Number of Contacts 26
Number of Poles 26
Number of Positions 26
Number of Rows 2
Orientation Vertical
Pitch 2.54 mm
Plating Tin
Radiation Hardening No
REACH SVHC Unknown
RoHS Compliant
Row Spacing 2.54 mm
Termination Solder
Voltage Rating 350 V
Voltage Rating (AC) 350 V
Voltage Rating (DC) 350 V
Working Voltage 350 V
Win Source Part Number 1033513-90130-1226
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 90130-1226 CAD Model

Description

The Molex 1033513-90130-1226 is a 2 row, 26 position, male vertical through-hole connector with a pitch of 2.54 mm.

  • Rows: 2
  • Positions: 26
  • Connector Type: Male Vertical
  • Mounting Type: Through-Hole
  • Pitch: 2.54 mm
  • Housing Material: Polyester
  • RoHS Compliant: Yes
  • Flammability Rating: UL94 V-0
  • Voltage Rating: 350 V
  • Current Rating: 3 A
  • Contact Resistance: 20 mΩ
  • Supply Status: Short Supply
