LQH2MPZ2R2MGRL

Name: LQH2MPZ2R2MGRL
Brand: Murata Electronics North America
SKU: 1370067
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	LQH2MPZ2R2MGRL
Manufacturer	Murata Electronics North America
Catalog	Fixed Inductors
Description	FIXED IND 2.2UH 680MA 468MOHM SM
Datasheet	LQH2MPZ2R2MGRL Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Inductors, Coils, Chokes - Fixed Inductors
Mfr	Murata Electronics
Series	LQH2
Package	Tape & Reel
Product Status	Active
Type	Drum Core, Wirewound
Material - Core	Ferrite
Inductance	2.2 µH
Tolerance	±20%
Current Rating (Amps)	680 mA
Current - Saturation (Isat)	1.18A
Shielding	Shielded
DC Resistance (DCR)	468mOhm Max
Frequency - Self Resonant	50MHz
Ratings	AEC-Q200
Temperature Range - Operating	-40°C ~ 105°C
Inductance Frequency - Test	1 MHz
Mounting Type	Surface Mount
Package / Case	0806 (2016 Metric)
Supplier Device Package	0806 (2016 Metric)
Size / Dimension	0.079" L x 0.063" W (2.00mm x 1.60mm)
Height - Seated (Max)	0.037" (0.95mm)
Base Product Number	LQH2MPZ
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8504.50.8000
Win Source Part Number	1370067-LQH2MPZ2R2MGRL
Ultra Librarian 3D Model	Ultra Librarian LQH2MPZ2R2MGRL CAD Model

Alternative Products

Description

The LQH2MPZ2R2MGRL is a drum core, wirewound inductor from Murata Electronics.

Inductance: 2.2 μH
Current Rating: 680 mA
Size: 0.079" L x 0.063" W (2.00mm x 1.60mm)
Height: 0.037" (0.95mm)
Mounting Type: Surface Mountable
Package: 0806 (2016 Metric)
Tolerance: ±20%
Q factor: - @ 10MHz
Self-Resonant Frequency: 50MHz
DC Resistance (DCR): 468mOhm Max
Shielded: Yes
Material: Ferrite
AEC-Q200: Yes
