74HCT574D,653 Nexperia USA Inc. 74HCT574D,653 real image 74HCT574D,653 label picture
Same model may have multiple batches, images only for reference.
74HCT574D,653 Nexperia USA Inc. 74HCT574D,653 real image 74HCT574D,653 label picture
74HCT574D,653 Nexperia USA Inc. 74HCT574D,653 real image 74HCT574D,653 label picture
Same model may have multiple batches, images only for reference.

74HCT574D,653

Part No 74HCT574D,653
Manufacturer Nexperia USA Inc.
Catalog Logic - Flip Flops
Description IC D-TYPE POS TRG SNGL 20SOIC
Datasheet
74HCT574D,653 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Nexperia USA Inc.
Packaging Reel - TR
Status Active
Purpose Standard
Type D-Type
Output Type Tri-State, Non-Inverted
Number of Elements 1
Number of Bits per Element 8
Max Frequency 76MHz
Max Propagation Delay @ V, Max CL 33ns @ 4.5V, 50pF
Trigger Type Positive Edge
Current - Output High, Low 6mA, 6mA
Supply Voltage - Operating 4.5 V to 5.5 V
Current - Quiescent 8μA
Input Capacitance 3.5pF
Temperature Range - Operating -40°C to 125°C (TA)
Mounting SMD (SMT)
Dimension 20-SOIC (0.295", 7.50mm Width)
Win Source Part Number 1008833-74HCT574D,653
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian 74HCT574D,653 CAD Model

Description

The Nexperia USA Inc. 74HCT574D,653 is a D-type flip-flop IC.

  • Package: Reel
  • Mounting: Surface-mounting
  • Output Type: Non-inverted and tri-state
  • Current Output High: 6mA
  • Current Output Low: 6mA
  • Propagation Delay: 33ns @ 4.5V and 50pF
  • Quiescent Current: 8μA
  • Input Capacitance: 3.5pF
  • Maximum Frequency: 76MHz
  • Category: Digital logic ICs
  • Trigger: Positive edge
  • Supply and Demand Status: Sufficient
  • Popularity: Medium
