BC56-16PASX Real Image
Same model may have multiple batches, images only for reference.

BC56-16PASX

Part No BC56-16PASX
Manufacturer Nexperia USA Inc.
Catalog RF Transistors (BJT)
Description TRANS NPN 80V 1A DFN2020D-3 / Bipolar (BJT) Transistor NPN 80 V 1 A 180MHz 420 mW Surface Mount DFN2020D-3
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products>Transistors - Bipolar (BJT) - Single
Mfr Nexperia USA Inc.
Package Tape & Reel
Transistor Type NPN
Current - Collector (Ic) (Max) 1 A
Voltage - Collector Emitter Breakdown (Max) 80 V
Vce Saturation (Max) @ Ib, Ic 500mV @ 50mA, 500mA
Current - Collector Cutoff (Max) 100nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce 63 @ 150mA, 2V
Power - Max 420 mW
Frequency - Transition 180MHz
Temperature Range - Operating 150°C (TJ)
Mounting SMD (SMT)
Package / Case 3-UDFN Exposed Pad
Supplier Device Package DFN2020D-3
Base Product Number BC56
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.21.0075
Other Names 568-12649-2,934068133115,568-12649-1,568-12649-6-ND,568-12649-6,1727-2351-6,568-12649-2-ND,568-12649-1-ND,2156-BC56-16PASX-1727,1727-2351-2,1727-2351-1
Standard Package 3,000
Win Source Part Number 965038-BC56-16PASX
Ultra Librarian 3D Model Ultra Librarian BC56-16PASX CAD Model

Description

The Nexperia USA Inc. BC56-16PASX is a bipolar junction transistor that is designed for use in discrete semiconductor products.

  • Transistor Type: NPN
  • Maximum Power: 420 mW
  • Maximum Voltage: 80 V
  • Maximum Current: 1 A
  • Frequency Transition: 180MHz
  • Temperature Range: 150°C (TJ)
  • Package: 3-UDFN Exposed Pad
  • Popularity: medium
  • Supply and Demand Status: balanced
