The NPIS60P2R2MTRF is a shielded power inductor manufactured by NIC-Components Corp. It is designed for use in a variety of power supply and DC-DC converter applications. This inductor offers a combination of compact size and high performance, making it suitable for portable devices and other space-constrained applications.

Applications:

• DC-DC Converters
• Power Supplies for Portable Devices
• Buck Converters
• Boost Converters
• Point-of-Load (POL) Regulators

Features:

• Shielded Construction for Low EMI
• Compact Size: 6.0 x 6.0 x 3.0 mm
• High Saturation Current
• Surface Mount Design
• Operating Temperature Range: -40°C to +125°C
• Ferrite Core Material

Benefits:

• Reduced Electromagnetic Interference (EMI), ensuring stable operation of surrounding circuits.
• Space-saving design allows for miniaturization of electronic devices.
• High current handling capability ensures reliable performance under heavy loads.
• Easy to integrate into automated manufacturing processes using standard SMT techniques.
• Robust performance across a wide range of operating temperatures, suitable for harsh environments.

Technical Specifications:

Inductance: 2.2 µH
Tolerance: ±20%
Saturation Current: 2.6 A
DC Resistance (DCR): 65 mΩ (typical)
Self-Resonant Frequency (SRF): 70 MHz (typical)
Operating Temperature: -40°C to +125°C
Core Material: Ferrite
Termination: Tin Plating

The NPIS60P2R2MTRF inductor is designed to provide efficient and reliable power conversion in a small form factor. Its shielded construction minimizes electromagnetic interference, making it suitable for sensitive electronic devices. The high saturation current ensures stable performance under heavy loads, while the wide operating temperature range allows for use in various environments. This inductor is a great choice for designers looking for a high-performance, compact power inductor.
