M2018TXG13 Real Image
Same model may have multiple batches, images only for reference.

M2018TXG13

Part No M2018TXG13
Manufacturer NKK Switches
Catalog Rocker Switches
Description SWITCH ROCKER SPDT 0.4VA 28V / Rocker Switch SPDT 0.4VA (AC/DC) 28 V Through Hole
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Switches>Rocker Switches
Mfr NKK Switches
Series M
Package Bulk
Mounting Type Through Hole
Circuit SPDT
Switch Function Mom-Off-Mom
Current Rating (Amps) 0.4VA (AC/DC)
Voltage Rating - AC 28 V
Voltage Rating - DC 28 V
Actuator Type Actuator Arm, Cap Required
Actuator Marking Varies by Cap
Termination Style PC Pin
Features Epoxy Sealed Terminals
Temperature Range - Operating -30°C ~ 85°C
Mechanical Life 50,000 Cycles
Electrical Life 50,000 Cycles
Base Product Number M2018TX
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.50.9065
Other Names M2018TXG13-RO-ND,-M2018TXG13-RO,-M2018TXG13-RO-ND,M2018TXG13-RO,-M2018TXG13
Standard Package 1
Win Source Part Number 1173261-M2018TXG13
Ultra Librarian 3D Model Ultra Librarian M2018TXG13 CAD Model

Description

The M series rocker switch from NKK Switches is a SPDT circuit switch with mom-off-mom switch function.

  • Circuit: SPDT
  • Switch Function: mom-off-mom
  • Mechanical Life: 50,000 Cycles
  • Electrical Life: 50,000 Cycles
  • Current Rating: 0.4 VA (AC/DC)
  • Voltage Rating: 28 V AC and DC
  • Terminals: Epoxy Sealed
  • Mounting Type: Through-Hole
  • Termination Style: PC Pin
  • Temperature Range: -30°C ~ 85°C
  • ECCN: EAR99
