2N7002
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Discrete Semiconductor Products - Transistors - FETs, MOSFETs - Single FETs, MOSFETs
Mfr NTE
Package Bag
Product Status Active
FET Type N-Channel
Technology MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss) 60 V
Current - Continuous Drain (Id) @ 25°C 115mA (Ta)
Drive Voltage (Max Rds On, Min Rds On) 5V, 10V
Rds On (Max) @ Id, Vgs 7.5Ohm @ 500mA, 10V
Vgs(th) (Max) @ Id 2.5V @ 250µA
Vgs (Max) ±20V
Input Capacitance (Ciss) (Max) @ Vds 50 pF @ 25 V
Power Dissipation (Max) 200mW (Ta)
Temperature Range - Operating -55°C ~ 150°C (TJ)
Mounting Type Surface Mount
Supplier Device Package SOT-23-3
Package / Case TO-236-3, SC-59, SOT-23-3
Base Product Number 2N7002
Standard Package 1 pcs
ECCN EAR99
HTSUS 8541.21.0095
Win Source Part Number 844147-2N7002
Package Cut Tape (CT)
Drain to Source Voltage (Vdss) 60V
Drive Voltage (Max Rds On, Min Rds On) 5V, 10V
Rds On (Max) @ Id, Vgs 5 Ohm @ 500mA, 10V
Vgs (Max) 20V
Power Dissipation (Max) 225mW (Ta)
Operating Temperature 150°C (TJ)
Grade -
Supplier Device Package SOT-23
Package Tape & Reel (TR)
Current - Continuous Drain (Id) @ 25°C 600mA (Ta)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Rds On (Max) @ Id, Vgs 3Ohm @ 600mA, 10V
Vgs(th) (Max) @ Id 1V @ 250µA
Gate Charge (Qg) (Max) @ Vgs 4nC @ 10V
Input Capacitance (Ciss) (Max) @ Vds 474 pF @ 15 V
Power Dissipation (Max) 1.3W (Ta)
Operating Temperature -55°C ~ 150°C (TJ)
Ultra Librarian 3D Model Ultra Librarian 2N7002 CAD Model

Description

The 2N7002 is an N-channel MOSFET transistor with a drain-source voltage rating of 60 V.

  • Drain-Source Voltage: 60 V
  • Maximum Continuous Drain Current: 115mA @ 25°C
  • On-Resistance: 7.5 Ohms @ 500mA and 10V Gate-Source Voltage
  • Threshold Voltage: 2.5V @ 250μA
  • Power Dissipation: 200mW @ ambient temperature
  • Mounting Style: Surface Mount
  • Package: SOT-23-3
  • Input Capacitance: 50 pF @ 25V Drain-Source Voltage
  • Operating Temperature: -55°C to 150°C
  • Market Status: Active
