NTE864 NTE
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Specialized ICs
Mfr NTE
Package Bag
Product Status Active
Programmable Not Verified
Type Waveform Generator
Mounting Type Through Hole
Package / Case 14-DIP (0.300", 7.62mm)
Supplier Device Package 14-PDIP
Standard Package 1 pcs
MSL Level 1 (Unlimited)
REACH Status REACH info available upon request
ECCN EAR99
HTSUS 8542.31.0000
Win Source Part Number 261060-NTE864
Ultra Librarian 3D Model Ultra Librarian NTE864 CAD Model

Description

The NTE864 is a specialized IC that serves as a waveform generator.

  • Function: Waveform generator
  • Package: 14-DIP
  • Mounting: can be easily mounted on a circuit board
  • Features: programmable, offers flexibility in generating different types of waveforms
  • Operating Temperature Range: -40°C to 85°C
  • Status: active product from NTE
  • Applications: widely used in electronic systems that require waveform generation
