Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr NTE
Series RGP15
Package Bag
Product Status Active
Technology Standard
Voltage - DC Reverse (Vr) (Max) 200 V
Current - Average Rectified (Io) 1.5A
Voltage - Forward (Vf) (Max) @ If 1.3 V @ 1.5 A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr) 150 ns
Current - Reverse Leakage @ Vr 5 µA @ 200 V
Capacitance @ Vr, F 25pF @ 4V, 1MHz
Mounting Type Through Hole
Package / Case DO-201AD, Axial
Supplier Device Package DO-201AD
Standard Package 1 pcs
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 660224-RGP15D
Ultra Librarian 3D Model Ultra Librarian RGP15D CAD Model

Description

The RGP15D is a fast recovery diode designed for rectification applications. It has a maximum forward voltage of 1.3V @ a forward current of 1.5A, ensuring low power loss.

  • Maximum Reverse Recovery Time: 150 ns
  • Maximum Reverse Leakage Current: 5 µA @ a reverse voltage of 200V
  • Capacitance: 25pF @ a reverse voltage of 4V and a frequency of 1MHz
