Product Overview: 74AHC1G07GV by NXP

The 74AHC1G07GV is a high-speed Si-gate CMOS device from NXP Semiconductors, designed to deliver the functionality of a single non-inverting buffer with open-drain output. This integrated circuit is part of the 74AHC range, known for its high-speed operation while maintaining the robustness of CMOS technology.

Key Features

• Logic Type: The device features a non-inverting buffer logic gate that ensures signal integrity by restoring signal levels in digital circuits.
• Open-Drain Output: Allows for wired-AND logic configurations and is suitable for driving capacitive or resistive loads. The open-drain output also enables the device to be used in level-shifting applications.
• Operating Voltage: The 74AHC1G07GV operates within a wide range of supply voltages from 2.0V to 5.5V, making it versatile for interfacing with both TTL and CMOS logic levels.
• High-Speed Performance: With a typical propagation delay (tpd) of just 3.8ns at a supply voltage of 5V, it is optimized for high-speed signal processing.
• Low Power Consumption: It has a low ICC of just 1µA (max) at 25°C, minimizing power usage and heat generation.
• Temperature Range: The device can operate over a wide temperature range from -40°C to +125°C, ensuring reliability across various environmental conditions.
• Packaging: Available in a very small SOT-753 (SOT23-5) surface-mount package, the 74AHC1G07GV is ideal for space-constrained applications.

Applications

The 74AHC1G07GV is suitable for a broad range of applications, including but not limited to:

• Level shifting for interfacing different logic levels.
• Line driving where multiple outputs can be connected to a single input line.
• Bus management and buffering in microcontroller systems.
• Memory address drivers, clock drivers, and bus transceivers.

Quality and Reliability

NXP Semiconductors is committed to delivering high-quality products. The 74AHC1G07GV is manufactured under strict quality control standards and is designed to meet the rigorous demands of the electronics industry. Its robust construction ensures long-term reliability, making it a trusted choice for critical applications.
