Products specifications Report Issue?

Manufacturer NXP
Win Source Part Number 1154916-BSS138PS
Manufacturer Homepage www.nxp.com
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Family Name BSS138PS
Introduction Date July 01, 2010
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian BSS138PS CAD Model

Description

Introducing the BSS138PS Dual N-Channel MOSFET from NXP Semiconductors

The BSS138PS is a high-performance, dual N-channel enhancement mode Field Effect Transistor (FET) brought to you by NXP Semiconductors, a leader in the electronics industry. This product is designed to deliver efficient power control and switching applications with its cutting-edge technology and compact form factor.

Encased in a small 6-pin SOT-363 package, the BSS138PS is optimized for space-sensitive applications while providing robust electrical characteristics. Each MOSFET in the BSS138PS can handle a continuous drain current of 200 mA, making it suitable for a variety of low-power applications. With a low on-resistance of 3.5 Ohms, it ensures minimal power loss and heat generation, enhancing the overall efficiency of your designs.

The device features a low threshold voltage of 1.5V (max), which enables operation at lower gate voltages, making it ideal for interfacing with low-voltage logic circuits and microcontrollers. This characteristic is particularly beneficial in battery-operated devices, where power conservation is of utmost importance.

Moreover, the BSS138PS boasts fast switching speeds, a critical attribute for high-frequency applications. Its fast switching capabilities ensure that devices can operate more efficiently, reducing energy consumption and improving performance in power management systems.

This dual MOSFET is also characterized by its high input impedance, which minimizes the loading effect on upstream circuits. This feature is significant when used in applications such as signal switching, where maintaining signal integrity is paramount.

The BSS138PS is designed with an eye on reliability, featuring built-in electrostatic discharge (ESD) protection. This protection safeguards the device from inadvertent static discharges, which can be detrimental to electronic components, especially in industrial and automotive environments where robustness is critical.

In summary, the BSS138PS from NXP Semiconductors is a versatile and reliable component suitable for a wide range of applications, including power management, load switching, and signal processing. Its compact size, low on-resistance, and fast switching speeds make it an excellent choice for designers looking to optimize their power-sensitive designs.
