Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer NXP
Packaging Tube
Status Obsolete
Core Processor HC05
Data Bus Width 8-Bit
Speed 2.1MHz
Connectivity SCI, SPI
Peripherals POR, WDT
The number of I/O 24
Program Memory Size 8KB
Program Memory Type OTP
Date RAM Size 304 x 8
Supply Voltage 3V ~ 5.5V
Temperature Range - Operating -40°C ~ 85°C
Mounting Style Through Hole
Manufacturer Package 40-DIP
Supplier Device Package 40-PDIP
Family Part Number MC705C8
Manufacturer Pack Quantity 9
MSL Level Not Applicable
Win Source Part Number 1219079-MC705C8ACPE
Manufacturer Homepage www.freescale.com
Family Name MC705C8A
Introduction Date August 07, 2005
ECCN EAR99
Country of Origin United States of America
Halogen Free Not Compliant
Estimated EOL Date Obsolete
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian MC705C8ACPE CAD Model

Description

The NXP MC705C8ACPE microcontroller is a robust, versatile, and high-performance 8-bit MCU designed to cater to a wide range of applications. With its advanced features and capabilities, this microcontroller is a perfect choice for designers and engineers looking for a reliable and efficient solution for their embedded systems.

Key Features:

  • CPU: The MC705C8ACPE is built around a HC05 core, which is a powerful 8-bit microcontroller architecture that provides a good balance between speed and power consumption.
  • Memory: It comes with 8KB of on-chip OTP (One-Time Programmable) ROM, which is ideal for storing firmware and applications that do not require frequent updates. Additionally, it includes 192 bytes of RAM for temporary data storage and efficient processing.
  • I/O Ports: This microcontroller features 38 general-purpose I/O pins, allowing for versatile interfacing with a wide range of peripherals and sensors.
  • Timers: Equipped with a 16-bit timer system, the MC705C8ACPE can handle complex timing tasks, which is essential for applications requiring precise timing such as motor control and event counting.
  • Analog-to-Digital Converter: An integrated 8-channel, 8-bit A/D converter allows for the direct measurement of analog signals, making it suitable for applications that require sensor data acquisition.
  • Communication Interfaces: The MCU supports serial communication via an SCI (Serial Communication Interface), enabling easy data exchange with other microcontrollers or computing systems.
  • Operating Voltage: It operates within a range of 3.0 to 5.5 volts, providing flexibility in power supply design and ensuring compatibility with both 5V and 3.3V logic levels.
  • Package: The device is offered in a 28-pin DIP (Dual In-line Package), which is widely used and suitable for prototyping and production in a variety of applications.

Applications:

The NXP MC705C8ACPE microcontroller is ideal for a multitude of applications, including but not limited to automotive control systems, home appliances, industrial automation, and consumer electronics. Its combination of analog and digital peripherals, along with its robust I/O capabilities, make it a flexible choice for designers who require a reliable MCU for their embedded solutions.

With its rich set of features and proven HC05 core, the MC705C8ACPE from NXP is engineered to meet the demands of modern embedded systems, delivering performance and efficiency without compromising on quality.
