The MSM56V16160F-10TK-FA is a 16Mbit synchronous DRAM (SDRAM) manufactured by OKI/Metcal. This memory chip is designed for applications requiring high-speed data access and large memory capacity.

Applications

• Graphics Cards: Used as memory to store textures and frame buffer data.
• Printers: Employed to buffer print data for high-resolution printing.
• Networking Devices: Utilized in routers and switches for packet buffering and forwarding.
• Embedded Systems: Integrated into various embedded systems that require substantial memory and fast data transfer rates.
• Industrial Control Systems: Used in industrial automation for data logging and real-time processing.

Features

• Capacity: 16Mbit (1,048,576 words x 16 bits)
• Operating Frequency: 100 MHz
• Interface: Synchronous, compliant with JEDEC standards.
• Power Supply: 3.3V power supply.
• Refresh: Auto-refresh and self-refresh modes.
• Package: TSOP (Thin Small Outline Package) for efficient board space usage.
• Latency: Low latency operation for improved performance.

Benefits

• High Performance: Provides fast data access due to its synchronous interface and high operating frequency.
• Large Capacity: 16Mbit capacity enables the storage of substantial amounts of data.
• Low Power Consumption: Designed for low power operation, which is essential for battery-powered devices and energy-efficient systems.
• Compact Size: TSOP package allows for space-saving integration into various devices.
• Reliability: Manufactured to high-quality standards, ensuring long-term reliability.

Additional Details

The MSM56V16160F-10TK-FA supports burst read and write operations, which further enhances data transfer rates. Its auto-refresh and self-refresh capabilities reduce the need for external memory control, simplifying system design. The chip is also designed to operate within a wide temperature range, making it suitable for various environmental conditions. The specific -10 indicates the speed grade, relating to a 10ns access time.
