Products specifications

Manufacturer ON Semiconductor
Packaging Bulk
Part Status Obsolete (End Of Life)
Diode Type Schottky
Voltage - DC Reverse (Vr) (Maximum) 60V
Current - Average Rectified (Io) 3A
Voltage - Forward (Vf) (Maximum) at If 740mV at 3A
Speed Fast Recovery = 200mA (Io)
Current - Reverse Leakage at Vr 600μA at 60V
Mounting Style Through Hole
Manufacturer Package DO-201AA, DO-27, Axial
Supplier Device Package DO-201AD
Operating Temperature - Junction -65°C ~ 150°C
Part Number Series MBR360
Manufacturer Pack Quantity 500
MSL Level 1 (Unlimited)
Popularity Medium
Supply and Demand Status Balance
Win Source Part Number 807700-MBR360
Ultra Librarian 3D Model Ultra Librarian MBR360 CAD Model

Description

The MBR360 from ON Semiconductor is a robust Schottky barrier rectifier designed for high-efficiency power supply applications. This 3A, 60V rectifier is engineered to provide low forward voltage drop, minimizing energy loss and improving system efficiency, particularly in low voltage, high-frequency inverters, free-wheeling, and polarity protection applications.

Key Features

  • High Surge Capacity: The MBR360 is capable of withstanding high surge currents, making it ideal for applications that may experience occasional surges.
  • Low Power Loss: With its low forward voltage drop and low reverse leakage, the MBR360 ensures minimal power loss, thus improving the overall efficiency of the circuit.
  • High Frequency Operation: The device's fast switching capability makes it suitable for use in high-frequency power supplies and other power switching applications.
  • Thermal Stability: The MBR360 can operate over a wide temperature range, maintaining its performance even under thermal stress.
  • Package Options: It is available in various package options, including the popular axial leaded package, which is easy to install and handle.

Applications

  • Switching power supplies
  • Converters
  • Free-wheeling diodes
  • Reverse battery protection
  • DC-DC converters
  • Automotive applications

Reliability and Quality

ON Semiconductor is known for its commitment to quality and reliability, and the MBR360 is no exception. Each device is rigorously tested to ensure it meets the high standards expected of industrial and automotive-grade components. With its low forward voltage and high surge capability, the MBR360 is an excellent choice for designers looking for a reliable and efficient Schottky rectifier.

Environmental Compliance

The MBR360 complies with RoHS and REACH environmental standards, ensuring that it is free from hazardous substances and is safe for use in electronic equipment.
