ON Semiconductor MC100EPT20DR2G

The MC100EPT20DR2G is a cutting-edge differential LVPECL to LVTTL translator integrated circuit designed by ON Semiconductor, a leader in energy-efficient innovations. This high-performance device is engineered to convert two LVPECL level signals into LVTTL level signals with precision and reliability. It is a crucial component in various digital systems where signal integrity and translation speed are paramount.

Key Features

• High-Speed Performance: The MC100EPT20DR2G boasts a typical propagation delay of only 3.3 ns, ensuring rapid translation of signals for high-speed operations.
• Power Supply: This translator operates with a 3.3 V ±10% power supply, compatible with common LVTTL operating levels and suitable for a variety of applications.
• Temperature Range: The device is designed to function over the full industrial temperature range of -40°C to +85°C, making it versatile for use in harsh environments.
• Output Enable (OE) Feature: An OE input pin allows the user to place the outputs in high impedance for use in multi-point applications or when power conservation is needed.
• Package: Housed in a compact 8-lead SOIC package, the MC100EPT20DR2G is designed for space-efficient applications and easy integration into existing designs.

Applications

The MC100EPT20DR2G is suitable for a wide range of applications that require the translation of high-speed signals from PECL to TTL logic levels. This includes, but is not limited to:

• Networking equipment such as routers, switches, and hubs
• Telecommunications infrastructure
• Data communication systems
• Computers and computer peripherals
• Industrial control systems

ON Semiconductor's commitment to quality and performance is embodied in the MC100EPT20DR2G, making it an ideal choice for engineers and designers who require reliable signal translation in their digital systems. With its robust feature set and versatile applications, this product is a testament to ON Semiconductor's dedication to providing innovative solutions that meet the evolving needs of the electronics industry.
