MC74ACT125DR2G

Part No MC74ACT125DR2G
Manufacturer ON Semiconductor
Catalog Logic - Buffers, Drivers, Receivers, Transceivers
Description IC BUFF TRI-ST QD N-INV 14SOIC
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer ON Semiconductor
Packaging Reel - TR
Status Active
Logic Type Buffer, Non-Inverting
Number of Elements 4
Number of Bits per Element 1
Output Type Push-Pull
Current - Output High, Low 24mA, 24mA
Supply Voltage - Operating 4.5 V to 5.5 V
Temperature Range - Operating -40°C to 85°C (TA)
Mounting SMD (SMT)
Case / Package 14-SOIC
Win Source Part Number 006494-MC74ACT125DR2G
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian MC74ACT125DR2G CAD Model

Description

ON Semiconductor MC74ACT125DR2G: Quad Buffer with 3-State Outputs

The MC74ACT125DR2G from ON Semiconductor is a high-performance, quad buffer integrated circuit designed to operate at exceptionally high speeds with a significant reduction in power consumption. This device is a member of the high-speed CMOS ACT family, featuring four independent non-inverting buffer gates with 3-state outputs.

This versatile component is housed in a compact SOIC-14 package, making it suitable for space-constrained applications. The MC74ACT125DR2G is designed to interface with TTL levels while maintaining CMOS low power dissipation. It is characterized for operation from -40°C to 85°C, ensuring reliable performance across a wide range of environmental conditions.

Key Features

  • Logic Type: Quad Buffer, Non-Inverting
  • Output Type: 3-State
  • Number of Channels: 4
  • Supply Voltage Range: 4.5V to 5.5V
  • Operating Temperature: -40°C to 85°C
  • Package: SOIC-14
  • Lead-Free and RoHS Compliant: Yes

The 3-state outputs ensure that the device can be used in bus-oriented applications, where multiple outputs can share a common connection without interference. When the output enable (OE) input is high, the output is in a high-impedance state, effectively disconnecting it from the bus or common connection.

ON Semiconductor's MC74ACT125DR2G is ideal for a broad range of applications, including driving bus lines or buffer memory address registers. Its fast switching speeds and low power consumption make it a preferred choice for modern digital systems where efficient data flow and minimal power usage are critical.

With its robust design and adherence to industry-standard specifications, the MC74ACT125DR2G is a reliable and cost-effective choice for designers looking to add high-speed buffering capabilities to their digital systems. The product's commitment to quality and performance is backed by ON Semiconductor's reputation as a leading manufacturer of semiconductor components.
