Product Overview: MC74VHC1G09DFT1G

The MC74VHC1G09DFT1G is a high-performance, single 2-input AND gate with open-drain output, designed and manufactured by ON Semiconductor. This advanced CMOS logic gate is part of ON Semiconductor’s VHC series, which is renowned for its low power consumption and high noise immunity equivalent to JEDEC standard no. 17A. It is specifically tailored for use in 3.3V and 5V systems, making it highly versatile for a wide range of applications.

Key Features

• High Speed: The device boasts a propagation delay time of approximately 5.5 ns at VCC = 5V, ensuring swift signal processing for time-sensitive applications.
• Low Power Consumption: With a low power-down leakage current and a low quiescent supply current of 1µA maximum, the MC74VHC1G09DFT1G is ideal for power-sensitive designs.
• Open-Drain Output: This feature allows for the connection of multiple outputs to achieve wired-AND configurations, providing greater flexibility in complex logic circuits.
• Wide Operating Voltage Range: The device operates over a broad voltage range from 2V to 5.5V, accommodating diverse system requirements.
• High Noise Immunity: The MC74VHC1G09DFT1G exhibits noise immunity consistent with the VHC family of CMOS devices, ensuring reliable performance in electrically noisy environments.
• Lead-Free and RoHS Compliant: The product is available in a lead-free, 5-pin SC70 package, adhering to environmental standards and regulations.

Applications

The MC74VHC1G09DFT1G is suitable for a wide array of applications including, but not limited to:

• Logic level conversion for interfacing devices operating at different voltage levels
• Server farms and data center infrastructure where power efficiency is critical
• Portable and battery-powered electronics where power conservation is necessary
• Complex logic circuit implementations requiring wired-AND functions

Quality and Reliability

ON Semiconductor is committed to providing high-quality products. The MC74VHC1G09DFT1G is subjected to rigorous testing and quality control measures to ensure it meets the industry standards for performance and reliability. Customers can trust ON Semiconductor for consistent and dependable logic solutions.
