ON Semiconductor MC74VHC1G14DFT1G Single Schmitt-Trigger Inverter

The ON Semiconductor MC74VHC1G14DFT1G is a high-performance CMOS single Schmitt-Trigger inverter integrated circuit designed for use in a wide range of digital applications. This device features a single gate with Schmitt-Trigger input, which provides a hysteresis effect, allowing it to be used in noisy environments and to enhance noise immunity. The MC74VHC1G14DFT1G is fabricated using silicon gate CMOS technology which ensures that it has low power consumption while maintaining high-speed operation.

This inverter operates with a power supply voltage ranging from 2V to 5.5V, making it suitable for interfacing with both TTL and CMOS logic levels. Its low power consumption makes it ideal for battery-operated portable devices. The device is also characterized for operation from -55°C to +125°C, ensuring reliable performance in extreme environmental conditions.

The MC74VHC1G14DFT1G features balanced propagation delays and output transition times, providing consistent performance for critical timing applications. The input structure provides protection against static discharge, giving the device an added layer of robustness against electrical overstress.

The device is offered in a compact 5-pin SC-70 package, which is designed for space-constrained applications. Its small footprint is ideal for high-density circuit boards where space is at a premium.

Applications for the MC74VHC1G14DFT1G are diverse and include:

• Wave shaping and noise filtering
• Signal processing
• Glitch-free clock distribution
• Logic level conversion
• Pulse shaping
• Portable and battery-powered electronics

In summary, the ON Semiconductor MC74VHC1G14DFT1G is a versatile and reliable component for designers who require a high-performance Schmitt-Trigger inverter with low power consumption and high noise immunity. Its wide operating voltage range and robustness in various conditions make it an excellent choice for a multitude of digital applications.
