ON Semiconductor MMSZ5257BT1G Zener Diode

The MMSZ5257BT1G from ON Semiconductor is a highly reliable surface-mount Zener diode that offers excellent voltage regulation with a nominal Zener voltage of 33V. This diode is designed to provide a convenient and efficient solution for voltage regulation applications in a wide range of electronic circuits.

Constructed with ON Semiconductor's superior process technology, the MMSZ5257BT1G ensures a high level of performance and consistency. The product comes in a small and compact SOD-123 package, making it suitable for high-density circuit boards where space is at a premium.

Key Features:

• Zener Voltage (V<sub>Z): 33V
• Power Dissipation: 500mW, providing a good balance between power handling and compactness
• Tolerance: ±5% tolerance on nominal Zener voltage, providing precise voltage regulation
• Package: SOD-123, a small and flat package that is ideal for automated assembly processes
• Operating Temperature: -55°C to +150°C, suitable for a broad range of environmental conditions
• Quality and Reliability: ON Semiconductor's commitment to high-quality standards ensures product reliability
• RoHS Compliant: Environmentally friendly, meeting RoHS directives for hazardous substance restrictions

Applications:

The MMSZ5257BT1G Zener diode is versatile and can be used in various applications, including:

• Voltage regulation modules
• Overvoltage protection circuits
• Switching power supplies
• Consumer electronics
• Computers and peripherals
• Telecommunication devices

With its robust design and precise voltage regulation, the MMSZ5257BT1G is an excellent choice for designers looking for a dependable Zener diode solution. Whether it's for a sophisticated industrial system or a simple consumer electronic device, this product from ON Semiconductor stands out for its performance, durability, and ease of integration into various circuit designs.
