Products specifications

Category Integrated Circuits (ICs) - Audio Special Purpose
Mfr ON Semiconductor
Package Tape & Reel
Product Status Obsolete
Function Compandor
Applications Consumer Audio, Telecommunication Systems
Number of Channels 2
Interface Analog
Voltage - Supply 6V ~ 18V
Temperature Range - Operating -40°C ~ 85°C (TA)
Specifications 110dB
Mounting Type Surface Mount
Package / Case 16-SOIC (0.295", 7.50mm Width)
Supplier Device Package 16-SOIC
Base Product Number SA571
Standard Package 1,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 663410-SA571DR2
Ultra Librarian 3D Model Ultra Librarian SA571DR2 CAD Model

Description

The SA571DR2 is a versatile and high-performance audio processor integrated circuit (IC) developed by ON Semiconductor. It is designed to cater to a wide array of audio applications, from professional audio systems to consumer electronics. This compact and efficient IC is an ideal solution for dynamic range compression and expansion, which are essential in achieving superior sound quality in various environments.

Key Features

  • Dynamic Range Control: The SA571DR2 offers excellent dynamic range compression and expansion, enabling automatic adjustment of audio signal levels for optimal listening experiences.
  • Low Distortion: It boasts low distortion characteristics, ensuring the audio output remains clear and true to the original source.
  • Wide Operating Voltage Range: This IC operates over a wide voltage range, accommodating different power supply specifications and ensuring flexibility in system design.
  • Adjustable Parameters: Users can adjust attack and release times, making it highly adaptable to various audio dynamics requirements.

Applications

The SA571DR2 is suited for a variety of applications, including but not limited to:

  • Professional Audio Equipment
  • Consumer Electronics
  • Wireless and Wired Communication Devices
  • Automotive Audio Systems
  • Sound Processing Modules

Technical Specifications

Parameter Value Package SOIC-16 Operating Temperature -40°C to +85°C Supply Voltage 4.5V to 18V Gain Adjustment Range Up to 40 dB

With its robust design and feature-rich capabilities, the ON Semiconductor SA571DR2 stands out as a premier choice for designers seeking to enhance their audio systems' performance. Its integration into your audio processing chain will result in a remarkable improvement in sound quality, dynamic control, and overall auditory experience.
